Hubbell Wiring Device-Kellems HBL6375S Flanged Inlet, 50A 125/250V, 3-Pole, Steel, 3.80 Inch x 3.43 Inch x 3.75 Inch
- MPN: HBL6375S
- UPC: 783585369594
- PPN: HBL-HBL6375S
- UNSPSC: 39121406
CAD
$501.92
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Temporary Power Products, Spider Portable Power, Replacement Parts, Flanged Inlet, 50A 125/250V
Features
- Metallic flanged casing provides maximum strength and protection
- Thermoset interior provides superior heat resistance
- Spider Box Replacement
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | United States |
|---|---|
| Dimensions | 3.80 in x 3.43 in x 3.75 in |
| Industry Standard(s) | Certified to CSA C22.2 No.42;Listed to UL 498 |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V0;Environmental - Operating Temperatures - Maximum continuous 75°C minimum –40°C (w/o impact);Mechanical - Terminal Accommodation - #10 AWG - #6 AWG solid or stranded copper wire only |
| Amperage Rating | 50 A |
| Color | Black |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Phase | Single Phase |
| Special Features | Spider Box Replacement |
| Type | Replacement Part |
| Wire Size | #10 AWG to #6 AWG |
| Weight | 0.80 lb. |
| General Literature Asset 1 Display Text | Pulp & Paper Solutions |
| Connectivity | Screw Terminals |
| Number Of Poles | 3-Pole |
| Style | Inlet |
| Description - Invoice | REP LKG INLET, SPIDER 50A |
| Harmonization Code | 8536694020 |
| MSDS Flag | No |
| Material - Mounting Hardware | Screw Mounting |
| Material | Steel, Zinc Plated |
| BOX SIZE | 4.000x4.800x4.800 (in) |
| Carton - Number of Sub Packs | 10 |
| Carton - SCC-14 Next Lower Level Sub Pack | 783585369594 |
| Case Weight | 0.750 lb. |
| Lowest Level UOM | Each |
| Pallet Height | 46.800 in |
| Pallet Weight | 747.000 lb. |
| NAICS Code | 335931A102 |
| Current / Amperage Rating | 50 A |
|---|---|
| Height | 3.75 in |
| Length | 3.80 in |
| Standards - RoHS Compliance Status | CM |
| Application | Heavy Duty Industrial |
| Dielectric Strength | Withstands 2,000V minimum |
| Number of Poles | 3-Pole |
| Size | 3.80 in x 3.43 in x 3.75 in |
| Standard | Certified to CSA C22.2 No.42;Listed to UL 498 |
| Voltage Rating | 125/250 V |
| Voltage Rating Description | 125/250 V |
| Width | 3.43 in |
| General Literature Asset 2 Display Text | PULP & PAPER SOLUTIONS |
| Display Size | Standard Sized Product |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without Impact |
| Class Code | A20 |
| Freight Class Code | 06168002 |
| Image Actual Or Representative | A |
| Sub Class Code | A20A270 |
| Current Rating | 50 A |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 10.150 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 10 EA |
| Each - Pack Description | Each |
| Pallet - GTIN - Package | 70783585369593 |
| Pallet Length | 48.000 in |
| Pallet Width | 40.000 in |
