Cooper Lighting Solutions 14CGTS-NUV 1X4 CGT Selectable Lumens & CCT (3500K, 4000K, 5000K)
- MPN: 14CGTS-NUV
- UPC: 080083247806
- PPN: COL-14CGTS-NUV
- UNSPSC: 30161602
CAD
$73.77
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
1X4 CGT Selectable Lumens & CCT (3500K, 4000K, 5000K)
Features
- 49.409 IN Length 13.779 IN Width 1.968 IN Height
- 1x4, 2x2, and 2x4 sizes available
- Thin 2.5" inch height
- Selectable Lumens & CCT (3500K, 4000K, 5000K)
- 120-347V NUV Driver standard in all models
- DLC Certified
- Fits in shallow plenums with room to spare
- Robust die-formed steel housing is post-painted for maximum durability
- Acrylic microoptics provide uniform illumination from corner to corner
- Extruded aluminum bezel tightly sealed to the housing for durability
Documentation & Downloads
Specifications
Additional
- Lamp Type
- LED
- Wattage
- 41.0 W max
- Color Temperature
- 3500K - 5000K
- Efficacy
- 108 to 130 lm/W
- Length
- 49.409 in.
- Height
- 1.968 in.
- Weight
- 4.74 Pounds
- Ingress Rating
- IP5X
- Country of Origin
- CN
Voltage120-347V
Lumen Output4486 MAX lumens
CRI (Minimum)85
Mounting TypeCeiling Mount
Width13.779 in.
Size1'x4'
MaterialSteel, Aluminum, Acrylic
ComplianceDLC Certified, cULus Listed, UL Damp Location Listed, IC Rated, FCC Part 15 Class B, RoHS
