Pass & Seymour PTTR8300PILA PlugTail® 20A 125V Extra-Heavy Duty Hospital-Grade Duplex Receptacle, Light Almond, 1.625 Inch Width, 2.75 Inch Height
Pass & Seymour PTTR8300PILA PlugTail® 20A 125V Extra-Heavy Duty Hospital-Grade Duplex Receptacle, Light Almond, 1.625 Inch Width, 2.75 Inch Height
- MPN: PTTR8300PILA
- UPC: 785007041354
- PPN: P-S-PTTR8300PILA
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$51.08/ EA
Description
Built for the harshest medical environments, Pass and Seymour power indicating receptacles feature two industry-exclusive green LEDs that offer clear visual assurance of power indication at the receptacleeven with critical equipment plugged into the device. The LEDs operate independently from one another to accommodate split-circuit wiring installations. Tamper-resistant protection comes standard with each receptacle to further enhance safety. For detailed PlugTail® information, visit our PlugTail® Headquarters.
Features
- .036 inch thick, brass, triple-wipe power contacts for lasting retention.
- GE Lexan high impact-resistant lens.
- No exposed terminals create a finger safe application before, during, and after installation.
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
- Crimped and welded contacts.
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
- Pre-stripped connector leads fasten to conductors, easier than standard pigtails.
- Auto-ground clip assures positive ground.
- For covering patents, see www.legrand.us/patents.
- Wire Size: #12 AWG THHN
Specifications
Specifications
- Depth
- 0.866 in
- Special Features
- Built for the harshest medical environments, Pass&Seymour PlugTail power indicating receptacles feature two industry-exclusive green LEDs that offer clear visual assurance of power indication at the receptacle—even with critical equipment plugged into the device. The LEDs operate independently from one another to accommodate split-circuit wiring installations. Tamper-resistant protection comes standard with each receptacle to further enhance safety.
- Phase
- Single
- Standard
- FSUL
- Amperage
- 20.0 A
- Standard
- FEDSPEC
- Number of Wires
- 3.0
- Indoor/Outdoor
- Indoor
- Wall Plate Included
- No
- Number of Receptacles
- 2.0
- Number of Poles
- Double Pole
- Application Sector
- Healthcare
- NEMA Configuration Code
- 5-20R
- Environmental Conditions
- UL94 V2
- Operating Temperature Max
- 60.0 °C
- Operating Temperature
- -40°-60°C
- Features
- Single Piece Plated Steel Mounting Strap
- Product Line
- Pass & Seymour
Height2.75 in
Width1.625 in
Country of OriginMexico
StandardcULus
Voltage125.0 V
StandardUL Listed
StandardCSA Listed
Wire Size14 - 10 AWG
Is Tamper-ResistantYes
Outlet TypeHospital Grade
Application SectorCommercial
Connection LocationBack Only
Wire Connection TypePlugTail
Warranty Type1-Year Limited Warranty
Operating Temperature Min-40.0 °C
Dielectric StrengthWithstands 2000V minimum
ColorLight Almond
