3M 5324 3M Motor Lead Pigtail Splice 5324, 5-8 kV, Shielded and Non-Shielded, 250-500 kcmil (feeder), 4/0 AWG-500 kcmil (motor lead), 1 per case

3M Motor Lead Pigtail Splice 5324, 5-8 kV, Shielded and Non-Shielded, 250-500 kcmil (feeder), 4/0 AWG-500 kcmil (motor lead), 1 per case

3M 5324 3M Motor Lead Pigtail Splice 5324, 5-8 kV, Shielded and Non-Shielded, 250-500 kcmil (feeder), 4/0 AWG-500 kcmil (motor lead), 1 per case

MPN: 5324
UPC: 054007122746
PPN: MMM-5324

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$1373.71/ EA

Loading add to cart quantity...

Description

Each kit makes three splices. Lugs not included in kits. Feeder of 250-500 kcmil (150-240 sq mm), motor lead 4/0 AWG-500 kcmil (120-240 sq mm).

Specifications

Specifications

RoHS 2011/65/EU Compliant: Yes

Trademark: 3M

Connection Type: Pigtail (Shielded)

Range Motor Lead (AWG & kcmil): 4/0-500

Range Feeder Cable (AWG & kcmil)250-500

Voltage5/8 kV

RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
