Burndy Q2A314NTN 4-Hole Copper Terminal for 2 Conductors 250-350 kcmil, 1/2 Inch Studs, 4.50 Inch Length
- MPN: Q2A314NTN
- UPC: 621945461062
- PPN: BUR-358446
CAD
$463.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
4-hole copper terminal; 2 conductors: 250-350 kcmil; 1/2" Studs; Tin Plated; NEMA Drilling
Documentation & Downloads
Specifications
Additional
| Voltage | 600 V |
|---|---|
| Temperature Rating | 194 F |
| Width | 3.00 in |
| Hole Size | 0.56 in (14 mm) |
| Number of Holes | 4 |
| Screw Type | Hexagonal Bolt |
| Plating Type | Tin - Electro Plated |
| Certification - UL Listed | Yes |
| Connector Type | Terminal |
| Trade Name | QIKLUGTM |
| Conductor Size Range | 250-350 kcmil |
|---|---|
| Length | 4.50 in |
| Height | 1.69 in |
| Stud Size | 1/2 in |
| Number of Screws | 2 |
| Material | Copper, Tin Plated |
| Installation Torque Recommended | 325 in-lb |
| Industry Standards | UL468A-468B, NEMA Drilling |
| Type | Bolted Lugs & Terminals |
