Telemecanique Sensors XZCE03P124M Adaptor, plastic, tapped hole M20, for male connector, M12, 4 wire

MPN: XZCE03P124M
PPN: TES-XZCE03P124M

$122.98

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Adaptor, plastic, tapped hole M20, for male connector, M12, 4 wire

Documentation & Downloads

Specifications

Key Specifications

Thread Type	M20 x 1.5
Accessory / Separate Part Category	cabling accessories
Cable Composition	4 x 0.34 mm²

Accessory / Separate Part Designation	4-wire connector adaptor
Line Rated Current	4 A
Accessory / Separate Part Type	connector adaptor

Complementary

Total Number Of Wires	4
Maximum Resistance Across Terminals	5000 mOhm
Cable Connector Fixing	screw-on
Electrical Connection	1 male connector M12 5 straight
Net Weight	0.02 kg

[Ue] Rated Operational Voltage	30 V AC \|\| 36 V DC
Insulation Resistance	> 1000000000 Ohm
Cable Length	100 mm
Body Material	plastic

Environment

Ambient Air Temperature For Operation	-25-80 °C

Ip Degree Of Protection	IP67

Contractual warranty

Warranty	18 months

Offer Sustainability

Rohs Exemption Information	Yes
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
California Proposition 65	WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
