Tripp Lite AV550SC 550VA Audio/Video Backup Power Block with 4 AC Outlets and Surge Suppression
- MPN: AV550SC
- UPC: 037332138699
- PPN: TRP-AV550SC
CAD
$668.07
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
550VA Audio/Video Backup Power Block with 4 AC Outlets and Surge Suppression
Features
- 4 AC outlets (including 1 delay-on outlet for router)
- Automatic recycle/reset button; Auto-restart capability
- Regulated 12V DC output for 4 devices; Complete surge suppression
- Convenient installation fits structured wiring enclosures without using mounting screws or brackets
- HD-compatible 2.2GHz coaxial and telephone/modem/DSL line surge protection; 550VA UPS capacity
- 2-year limited warranty
Documentation & Downloads
Specifications
Additional
- Output Volt Amp Capacity
- 550 VA
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Output Receptacle Detail
- One receptacle has 60 second power-up delay for router
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Input Rated Current (Maximum Load)
- 10 A
- UPS Input Connection Type
- 5-15P; C14 inlet (detachable 5-15P input cable via C14 inlet)
- Recommended Electrical Service
- 15A 120V
- Input Circuit Breakers
- 10A
- Half Load Runtime
- 9.7 min (150W)
- Battery Recharge Rate
- Less than 9 hours from 10% to 90%
- LED Indicators
- 2 LEDs indicate power status and overload/low battery
- EMI / RFI AC Noise Suppression
- Yes
- Installation Form Factor
- Wallmount
- Dimensions (H x W x D)
- 8.3 x 6.8 x 3.0 in (211 x 173 x 76 mm)
- Operating Temperature Range
- 32 to 104 °F (0 to 40 °C)
- Relative Humidity
- 0 to 95%, non-condensing
- Low Voltage Transfer Setpoint
- 99 V
- Energy Efficiency
- >95%
- Warranty
- 2-year limited
Output Watt Capacity300 W
Output Receptacles(4) 5-15R
Output AC Waveform (AC Mode)Sine wave
Nominal Output Voltage110V, 115V, 120V
Nominal Input Voltage120V AC
UPS Input Cord Length0.5 ft
Input PhaseSingle-Phase
Full Load Runtime3.1 min (300W)
DC System Voltage12 VDC
SwitchesOne on/off push button with recycle/reset function
Dataline Surge ProtectionTelephone/DSL; Coax (HD-compatible 2.2GHz)
AC Suppression Joule Rating1038
Primary Form FactorDesktop
Weight7.8 lbs (3.54 kg)
Storage Temperature Range5 to 122 °F (-15 to 50 °C)
Transfer Time4 ms
High Voltage Transfer Setpoint139 V
ComplianceUL1778, CSA, NOM, FCC Part 15 B, FCC Part 68, Industrie Canada, RoHS
