Schmersal 103007356 Magnetic Safety Sensor, 4-Pole, 5 Meter Cable, IP65/IP67, Black
- MPN: 103007356
- PPN: SCM-103007356
CAD
$61.06
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Magnetic Safety Sensor, 4-Pole, 5 Meter Cable, IP65/IP67, Black
Features
- Pre-wired cable
- 4-pole
Documentation & Downloads
Specifications
Electrical data
- Thermal test current
- 4 A
- Rated operating voltage
- 30 VDC
Rated operating voltage30 VAC
Operating current4,000 mA
Pin assignment
- PIN 1
- Brown
- PIN 3
- Blue
PIN 2White
PIN 4Black
Mechanical data - connector side A
- Connector typ
- Female connector, M8
- Connector latching
- Screw locking
- Material of the handle
- Plastic, TPU
Designstraight
Material of the glandMetal, CuZn, nickel-plated
Colour of the handleBlack
General data - Features
- Halogen free
- Yes (1)
- Number of poles
- 4
Cable drag chain suitableYes (1)
General data
- Standards
- EN IEC 61076-2-104
Gross weight151 g
Ambient conditions
- Degree of protection
- IP65 | IP67
- Ambient temperature (fixed)
- -50 ... +90 °C
Ambient temperature (Connector)-30 ... +90 °C
Ambient temperature (moved)-30 ... +90 °C
Mechanical data - Connection technique
- Length of cable
- 5 m
- Cable diameter
- 4.3 mm
- Bending radius (repeated)
- 10 x Ø-cable
- Material of the Cable mantle
- PUR
Wire cross-section0.34 mm
Bending radius (fixed)5 x Ø-cable
Colour of the Cable mantleBlack
Mechanical data
- Tightening torque, maximum
- 0.6 Nm
