Schmersal 131029937 Electromechanical Safety Interlock, 178mm Height, IP65/IP67, 24VDC
- MPN: 131029937
- PPN: SCM-131029937
CAD
$568.94
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Electromechanical Safety Interlock, 178mm Height, IP65/IP67, 24VDC
Features
- Manual release
- Thermoplastic enclosure
- Long life
- Interlock with protection against incorrect locking.
- 89 mm x 178 mm x 41 mm
- Actuating head can be repositioned by 4 x 90°
- 2 cable entries M 20 x 1.5
- Wiring compartment
- Slim design, particularly suitable for fitting on hinged doors, aluminium profiles and fencing
- Sealing mechanism to prevent the ingress of dirt
- Cut clamp termination
Documentation & Downloads
Specifications
Electrical data
- Thermal test current
- 4 A
- Required rated short-circuit current
- 1,000 A
- Switching element
- NO contact, NC contact
- Switching frequency
- 1.2 /h
Rated control voltage24 VDC
Electrical power consumption, maximum8.5 W
Switching principleslow action, positive break NC contact
Material of the contacts, electricalSilver
Note
- Note (Manual release)
- front | For maintenance, installation, etc. | For manual release using triangular key M3 (included in delivery)
Mechanical data - Dimensions
- Length of sensor
- 41 mm
- Height of sensor
- 178 mm
Width of sensor52 mm
Ambient conditions - Insulation values
- Rated insulation voltage U
- 250 VAC
Rated impulse withstand voltage U4 kV
Electrical data - Safety contacts
- Voltage, Utilisation category AC-15
- 230 VAC
- Voltage, Utilisation category DC-13
- 24 VDC
Current, Utilisation category AC-154 A
Current, Utilisation category DC-134 A
Scope of delivery
- Scope of delivery
- Actuator must be ordered separately.
Safety classification - Safety outputs
- B
- 2,000,000 Operations
B1,000,000 Operations
Electrical data - Magnet control
- Magnet switch-on time
- 100 %
- Test pulse interval, minimum
- 50 ms
Test pulse duration, maximum5 ms
General data - Features
- Power to unlock
- Yes
- Number of actuating directions
- 4
- Number of cable glands
- 2
Manual releaseYes
Number of auxiliary contacts1
Number of safety contacts2
General data
- Standards
- BG-GS-ET-19 | EN ISO 13849-1 | EN ISO 14119 | EN IEC 60947-5-1
- Working principle
- electromechanical
- Gross weight
- 480 g
Coding level according to EN ISO 14119Low
Enclosure materialGlass-fibre, reinforced thermoplastic
Electrical data - Auxiliary contacts
- Voltage, Utilisation category AC-15
- 230 VAC
- Voltage, Utilisation category DC-13
- 24 VDC
Current, Utilisation category AC-154 A
Current, Utilisation category DC-134 A
Safety classification
- Standards
- EN ISO 13849-1
Mission time20 Year(s)
Other data
- Note (applications)
- sliding safety guard | removable guard | hinged safety guard
Ambient conditions
- Degree of protection
- IP65 | IP67
Ambient temperature+0 ... +50 °C
Mechanical data - Connection technique
- Termination
- Screw terminals
- Cable section, minimum
- 0.5 mm²
- Note (Cable section)
- All indications including the conductor ferrules.
Cable entry2 x M20 x 1,5
Cable section, maximum1.5 mm²
Mechanical data
- Mechanical life, minimum
- 1,000,000 Operations
- Holding force F
- 2,550 N
- Positive break force, minimum
- 20 N
Holding force F1,950 N
Latching force20 N
Actuating speed, maximum0.3 m/s
Approvals - Standards
- Certificates
- TÜV | cULus | CCC
