nVent Hoffman A61-DTCOVERKIT Inspection Window Cover, 23.74 Inch x 11.89 Inch x 1.77 Inch, Fiberglass
- MPN: A61-DTCOVERKIT
- UPC: 635394571050
- PPN: HOF-A61-DTCOVERKIT
- UNSPSC: 39121324
CAD
$581.54
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
APO DT Covers designed for inspection windows in corrosive environments for easy viewing and access. This APO DT Trnsp Hngd Scr Cvr Insp Wdw Blk Insrt, A61-DTCOVERKIT item measures 23.74x11.89x1.77 with material Fiberglass finish Smooth.
Features
- Available sized from 12” x 7” to 24” x 12” (H x W)
- DT Covers are maintenance free and corrosion resistant
- Frames are made from hot compression molded halogen free, self extinguishing fiberglass reinforced polyester (FRP) that can withstand continuous temperatures from -58°F to 302°F (-50°C to 150°C)
- Inspection windows are made from transparent polycarbonate that can withstand continuous temperatures to 248°F (120°C)
- Included thumb screw inserts allow quick window opening for access to interior component
- Gaskets are made from continuously poured polyurethane foam
Documentation & Downloads
Specifications
Additional
- Material
- Fiberglass
- Size
- 23.74 x 11.89 x 1.77 in
- Color
- Light Gray
- Height (H)
- 603 mm
- Depth (D)
- 45 mm
- Gasket Material
- Polyurethane foam
FinishSmooth Matte
Weight4.55 lb
Color CodeRAL 7035
Width (W)302 mm
Temperature Range-58°F to 302°F (-50°C to 150°C) base, up to 248°F (120°C) window
ComplianceUL Types 3, 3R, 4, 4X, 12 & 13; CSA 3, 3R, 4, 4X, 12 & 13; IEC/EN IP67, IK10, 60439-1, 62208
