Square D SL225 Circuit breaker accessory, I-Line, bolt on, sub feed lugs, 225A

Circuit breaker accessory, I-Line, bolt on, sub feed lugs, 225A

Square D SL225 Circuit breaker accessory, I-Line, bolt on, sub feed lugs, 225A

MPN: SL225
UPC: 785901205630
PPN: SCH-SL225

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Loading dialog...

Looking to buy a large quantity?

To view product inventory

CAD$284.55/ EA

Loading add to cart quantity...

Description

Square standard I-Line circuit breaker is designed to provide a high quality, secure connection between the distribution bus and circuit breaker I-Line circuit breakers with bolted connections have clamp-on jaws that are bolted around the main bus, as shown. The bolt-on I-Line design is offered as an alternative in order to meet specifications requiring a bolted connection. This sub-feed lug kit offers I-line Bolt construction could be used with molded case circuit brakers (not available for PowrPact circuit breakers). This I-line sub-feed lug kit has 225A current rating.

Specifications

Specifications

Range Of Product: I-Line

Product Or Component Typesub-feed lug

Offer Sustainability

China Rohs Regulation: Product out of China RoHS scope. Substance declaration for your information

Rohs Exemption Information: Yes

Environmental Disclosure: ENVPEP1406032EN

Pvc Free: Yes

Reach Regulation: Reference contains Substances of Very High Concern above the threshold

Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Circularity ProfileN/A

Mercury FreeYes

Sustainable Offer StatusGreen Premium product

Eu Rohs DirectiveCompliant with Exemptions

Halogen Content PerformanceHalogen free product

Complementary

[In] Rated Current: 225-225 A
