Blackburn X 1 N 4020 Insulated Aluminum Compression Splice 5-1/2 Inch for 4/0 ACSR/2/0 ACSR
Blackburn X 1 N 4020 Insulated Aluminum Compression Splice 5-1/2 Inch for 4/0 ACSR/2/0 ACSR
- MPN: X 1 N 4020
- PPN: T-B-X 1 N 4020
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$15.74/ EA
Description
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 4/0 ACSR, 4/0 Stranded, Gray, End B: 2/0 ACSR, 2/0 Stranded, 3/0 Stranded Compact, Gray, Die: 840.
Specifications
Packaging
- Inner Quantity
- 25
- Outer Quantity
- 100
- Weight Uom
- 0.18 lbs. Each
Inner Dimensions (inches)7.4x6.9x4.8
Outer Dimensions (inches)14.25x10x8.25
North American Specifications (UNSPSC)
- UNSPSC
- 39121449 Wire or cable compression splice
- Brand Name
- Blackburn
- Special Features
- Solid center barriers and large chamfers. Easy cable installation. Pre-filled with oxide inhibitor to prevent oxidation and keep out moisture. Constructed from Aluminum. Provides high conductivity. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized -Nylon Sleeves Rresist Installing-Tool Pressure and Provide Reliable 600V Insulation.
- Size
- 5-1/2 inches long
- Conductor Range
- Side A 4/0 ACSR/Stranded/Compressed, 250 Compact. Side B 2/0 ACSR, 2/0 Stranded, 2/0 Compressed, 3/0 Compact.
- Material
- Aluminum
- Insulation
- Insulated
IGCC4669 Wire or cable compression splice
TypeInsulated Aluminum Service Entrance Compression Splices
StandardANSI C119.4
ConnectionCrimp/Compression
Number Of Conductors2
ColorPink/Gray
