Blackburn UOG 48 Insulated Aluminum Service Entrance Compression Splice 2-25/32 Inch, ACSR #4, #8 Stranded
Blackburn UOG 48 Insulated Aluminum Service Entrance Compression Splice 2-25/32 Inch, ACSR #4, #8 Stranded
- MPN: UOG 48
- PPN: T-B-UOG 48
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$4.78/ EA
Description
Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 4 ACSR, 3-4 Stranded, 2 Solid, Green, End B: 8 Stranded, 6 Solid, Green, Die: 5/8.
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121449 Wire or cable compression splice
- Brand Name
- Blackburn
- Special Features
- Prefilled with Oxide Inhibitor and topped with color-coded end caps. Prevents oxidation and keeps out moisture. Solid Center Stops. Easy cable insertion. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized Nylon Sleeves Resist Installing-tool Pressure and Provide Reliable 600V insulaton.
- Standard
- ANSI C119.4
- Connection
- Crimp/Compression
- Number Of Conductors
- 2
- Color
- Orange/Blue
IGCC4669 Wire or cable compression splice
TypeInsulated Aluminum Service Entrance Compression Splices
ApplicationFor Standard Comductors
Size2-25/32 inches long
Conductor RangeSide A #4 ASCR, #4 Stranded, #2 Solid. Side B #8 Stranded, #6 Solid
MaterialAluminum
InsulationInsulated
Packaging
- Inner Quantity
- 100
- Outer Quantity
- 500
- Weight Uom
- 5 lbs. per 100
Inner Dimensions (inches)16.1x5.4x4.2
Outer Dimensions (inches)22x17x5.5
