Blackburn

Blackburn SG 1010 AL TINPLT STR SPLICE DIE 5/8 1/01/0

AL TINPLT STR SPLICE DIE 5/8 1/01/0
  • MPN: SG 1010
  • UPC: 783786751624
  • PPN: T-B-SG 1010
  • UNSPSC: 39121449

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$20.00/ EA

Description

Tin Plated Aluminum Straight Splices - 5/8 common die series, wire size 1/0 Stranded - Compact - Compressed AL-CU. Installing Dies TU, 52, BG, 243, 5/8. Length 2 inch. Oxide Inhibitor. Yellow Caps.

Specifications

Additional Information

Brand / Label
Homac
Effective Date
20080619
Number of Conductors
2
Product Type
Compression Splice
Special Functions
Solid Center Stop assures accurate positioning and forces oxide inhibitor over and through conductor strands. Made from Aluminum which provides high strength and high conductivity. Prefilled with Oxide Inhibitor to Improve Contact and Seal out Moisture. Color Coded End Caps Seal Splices from Contaminants. All Splices marked with Conductor Sizes, Die References and Compression Locations for Easy Identification and Installation.
Surface Finishing
Tin-Plated
Connection TypeCompression
Insulation MaterialNone
Product NameELECTRICAL SPLICE<1000V
SizeLength 2 inches
StandardsANSI C119.4

Ordering

Country of Origin
United States (US)
Selling Unit of Measureeach

Classifications

WEEE Category
Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4669 >> Wire or cable compression splice
