Blackburn GLE 500 Non-Tension Splice

Non-Tension Splice

Blackburn GLE 500 Non-Tension Splice

MPN: GLE 500
UPC: 783786729647
PPN: T-B-GLE 500

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$60.87/ EA

Loading add to cart quantity...

Description

Aluminum Compression Splice, 500 kcmil Stranded, Compressed or Compact, Tin Plated. Dies CSA 28-12T, 317, 426. Oxide Inhibitor with Pink Caps. 4.0 inch Long. Oil Stop.

Specifications

North American Specifications (UNSPSC)

UNSPSC: 39121449 Wire or cable compression splice

Brand Name: Blackburn

Special Features: Use with Aluminum and Copper Conductors. Provide high strength and high conductivity. Prevents oxidation and keeps out moisture. Easy Identification. Assures proper cable insertion.

Standard: ANSI C119.4

Connection: Compression/Crimp

Number Of Conductors: 2

Finish: Tin-Plated

IGCC4669 Wire or cable compression splice

TypeNon-Tension Splice

ApplicationCompression Connector

SizeLength 4 inches

Conductor Range500

MaterialAluminum

InsulationNone

Packaging

Outer Quantity: 25

Weight Uom: 0.3 lbs. Each

Outer Dimensions (inches)6x6.5x7.5
