Schneider Electric TM5SAI4AFS Modicon TM5 Analog Input Module, 4 Inputs, 24-Bit Resolution, IP20
- MPN: TM5SAI4AFS
- PPN: SCH-TM5SAI4AFS
CAD
$2411.03
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safety analogue input module provides 4 inputs 0 to 20mA/4 to 20mA, 24-bit resolution. There is an isolation between channel and bus at 500V AC. This safety module, associated with TM5CSLC safety logic controller provides distributed safety solutions on Sercos bus up to SIL 3, Cat. 4, PL e, SIL CL3. It features 2 LEDs for power supply, 2 LEDs for safety status and 20 LEDs for input status signaling. It is furnished with 2 wires for electrical connection. Its housing colour is red. It weighs 0.068kg. It measure 75mm deep, 25mm wide, 99mm high. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon TM5CSLC safety logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Austria, Brazil, France |
|---|
| Depth | 60 mm |
|---|
Physical Attributes
| Color | Red |
|---|
| Housing Color | red |
|---|
Important Information Attributes
| Persona Type Ids | EU, OM, OM8 |
|---|---|
| Common Mode Rejection | > 70 dB, > 70 dB |
| Local Signalling | 1 LED green power supply, 1 LED red power supply4 LEDs green input status |
| Power Dissipation In W | 0.25 W, 1.7 W |
| Temperature Coefficient | +/-0.005 %FS/°C current, +/-0.005 %FS/°C current+/-0.005 %FS/°C current, +/-0.005 %FS/°C current |
| Certificate Agency | CSA, cULus |
| Carbon Footprint Of The End-of-life Phase [C1 To C4] | 0.10437299239986308, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Manufacturing Phase [A1 To A3] | 19 kg CO2 eq., 19.105955592975548 |
| Local Data Status | Publishable |
| Return Indicator | N |
| Stock Policy | 2 |
| Serviceability | No |
| Field Service Division | IDIBS |
| Weee Scope | Out |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | Yes |
| Tier Id | 1 |
| Function Option Id | ADVANCED |
| Market Segmentation Id | INDUSTRIAL |
| Product Kit Identifier | N |
| Electrical Connection | removable spring terminal block |
| Isolation Between Channels And Bus | 500 Vrms AC |
| Measurement Resolution | 1 µA, 4...20 mA |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Radio Standard Bluetooth | false |
| Radio Standard Gsm | false |
| Range Of Product | Modicon TM5 |
| Shock Resistance | 15 gn 11 ms |
| Supply | internal |
| Supporting Protocol For Can | false |
| Supporting Protocol For Devicenet Safety | false |
| Supporting Protocol For Foundation Fieldbus | false |
| Supporting Protocol For Knx | false |
| Supporting Protocol For Modbus | false |
| Supporting Protocol For Profibus | false |
| Supporting Protocol For Profinet Io | false |
| Supporting Protocol For Safetybus P | false |
| Supporting Protocol For Suconet | false |
| Total Lifecycle Carbon Footprint | 100 kg CO2 eq. |
| Vibration Resistance | 1 gn 8.4-150 Hz) on DIN rail3.5 mm 5-8.4 Hz) on DIN rail |
| Certified For Ul Hazardous Location Class Ii | false |
| Certified For Ul Hazardous Location Division 1 | false |
| Dc Supply Voltage | 24-24 V |
| Housing Color | red |
| Pep Code | ENVPEP1511025EN |
| Pep Verification Date | 2025-10-30 |
| Psr Version | PSR-0005-ed3.1-EN-2023 12 08 |
| Data Source | extrapolated product |
| Functional-unit Quantity | 1 |
| Reference Lifetime In Y | 10 |
| Energy Model - Manufacturing [A1-a3] | Electricity Mix; High voltage; 2020; Austria, AT |
| Energy Model - Use [B6] | Electricity Mix; Low voltage; 2020; Turkey, TR |
| Height Nominal | 105 mm |
| [Us] Rated Supply Voltage | 24 V DC -15...20 % |
| Appendant Operation Agent (Ex Ia) | false |
| Certified For Ul Hazardous Location Group A (Acetylene) | false |
| Certified For Ul Hazardous Location Group C (Ethylene)) | false |
| Certified For Ul Hazardous Location Group E (Metal Dusts) | false |
| Certified For Ul Hazardous Location Group G (Non Conductive Dust) | false |
| Performance Level According To En Iso 13849-1 | none |
| Radio Standard Wi-fi 802.11 | false |
| Supporting Protocol For Data-highway | false |
| Supporting Protocol For Interbus-safety | false |
| Wall Mounting/Direct Mounting Possible | false |
| Package Weight(Lbs) | 68.000 g |
| Warranty (In Months) | 18 |
| Persona Type Names | End User, Original Equipment Manufacturer, OEM - Control Panelbuilder |
|---|---|
| Load Impedance Ohmic | <= 230 Ohm current, <= 230 Ohm current<= 230 Ohm current, <= 230 Ohm current |
| Measurement Error | < 0.08 % of full scale 4...20 mA 25 °C, < 0.08 % of full scale 4...20 mA 25 °C, < 0.08 % of full scale 4...20 mA 25 °C< 0.08 % of full scale 4...20 mA 25 °C, < 0.08 % of full scale 4...20 mA 25 °C, < 0.08 % of full scale 4...20 mA 25 °C |
| Sampling Duration | 7 ms, 14 ms, 20 ms, 25 ms, 40 ms, 48 ms, 62 ms5 ms analog input |
| Typical Current Consumption | 2 mA 5 V DC, 38 mA 24 V DC input/output |
| Carbon Footprint Of The Distribution Phase [A4] | 0, 0 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase [A5] | 0 kg CO2 eq., 0.028091265679193185 |
| Carbon Footprint Of The Use Phase [B2 B3 B4 B6] | 81 kg CO2 eq., 80.67675928977035 |
| Local Publishable Date | 2026-01-12 |
| Stocking Flag | Y |
| Device Type | PLC System - PLC Component |
| Traceability | Yes |
| Average Life Duration | 20 year(s) |
| Scope Perimeter | At least in Europe |
| End Of Life Doc Ref | ENVEOLI1511025EN |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 1901 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | No |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Advanced |
| Market Segmentation | Industrial |
| Bearing Track Assembly Possible | false |
| Front Installation Possible | false |
| Marking | CE |
| Network Type | DC |
| Product Or Component Type | analog input module |
| Radio Standard Gprs | false |
| Radio Standard Umts | false |
| Returnability | No |
| Software Version | v6.2.5-6 |
| Supporting Protocol For Asi | false |
| Supporting Protocol For Devicenet | false |
| Supporting Protocol For Ethercat | false |
| Supporting Protocol For Interbus | false |
| Supporting Protocol For Lon | false |
| Supporting Protocol For Other Bus Systems | false |
| Supporting Protocol For Profinet Cba | false |
| Supporting Protocol For Profisafe | false |
| Supporting Protocol For Sercos | false |
| Sustainable Packaging | No |
| Type Of Cable | shielded cable |
| Certified For Ul Hazardous Location Class I | false |
| Certified For Ul Hazardous Location Class Iii | false |
| Certified For Ul Hazardous Location Division 2 | false |
| Fieldbus Connection Over Separate Bus Coupler Possible | false |
| System Accessory | false |
| Database Version | 2024-01 |
| Pcr Version | PCR-4-ed4-EN-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Functional-unit Description | To communicate with the remote I/O 100% of the time, for 10 years with a dissipated power of 2W. |
| Functional-unit Unit | unit |
| Energy Consumption On Product Lifetime In Kwh | 175.2 |
| Energy Model - Installation [A5] | No energy used |
| Energy Model - End Of Life [C1-c4] | Global, European and French datasets are used. |
| Width Nominal | 30 mm |
| Non-linearity | 0.003 %FS current |
| Appendant Operation Agent (Ex Ib) | false |
| Certified For Ul Hazardous Location Group B (Hydrogen) | false |
| Certified For Ul Hazardous Location Group D (Propane)) | false |
| Certified For Ul Hazardous Location Group F (Carbonaceous Dust) | false |
| Io-link Master Present | false |
| Rack-assembly Possible | false |
| Supporting Protocol For As-interface Safety At Work | false |
| Supporting Protocol For Ethernet/Ip | false |
| Supporting Protocol For Tcp/Ip | false |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8538908180 |
Environment Attributes Main
| Ambient Air Temperature For Operation | 0-40 °C vertical installation), 0-55 °C horizontal installation) |
|---|---|
| Take Back | No |
| Recycled Metal Content At Cr Level | 0 % |
| Toxic Heavy Metal Free | Yes |
| Carbon Footprint | 99.91517914082495 |
| Circularity Profile | ENVEOLI1511025EN |
| Eu Rohs Directive | Compliant |
| Operating Altitude | 0...6561.68 ft (0...2000 m) |
| Packaging Without Single Use Plastic | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Pep Code | ENVPEP1511025EN |
| Pcr Version | PCR-4-ed4-EN-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Product Compatibility | logic controller, motion controller |
|---|---|
| Reach Free Shvc | Yes |
| China Rohs Regulation | X |
| Mercury Free | Yes |
| Ambient Air Temperature For Storage | -25-70 °C-25-70 °C |
| Environmental Disclosure | ENVPEP1511025EN |
| Ip Degree Of Protection | IP20 |
| Packaging Made With Recycled Cardboard | No |
| Reach Free Of Svhc | Yes |
| Relative Humidity | 5-95 % without condensation |
| Pep Verification Date | 2025-10-30 |
| Psr Version | PSR-0005-ed3.1-EN-2023 12 08 |
General Attributes
| Product Or Component Type | analog input module |
|---|
| Range Of Product | Modicon TM5 |
|---|
ETIM
| ETIM 8 | EC001596 |
|---|
| ETIM 9 | EC001596 |
|---|
Input Attributes
| Analogue Input Resolution | 0...20 mA/4...20 mA, 24 bits |
|---|---|
| Analogue Input Number | 4 |
| Input Filtering | 1 ms configurable by software, 2 ms configurable by software, 10 ms configurable by software, 16.7 ms configurable by software, 20 ms configurable by software, 33.3 ms configurable by software, 40 ms configurable by software, 66.7 ms configurable by software |
|---|---|
| Analogue Input Type | current 4...20 mA |
