Weidmuller 1573010000 BLZ/SL KO OR BX
- MPN: 1573010000
- PPN: WDM-1573010000
CAD
$0.34
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
PCB plug-in connector, Accessories, Coding element, orange, Number of poles: 1
Documentation & Downloads
Specifications
Approvals
| Approvals | EAC |
|---|
| ROHS | Conform |
|---|
Dimensions And Weights
| Net weight | 0.69 g |
|---|
Rated Data Acc. To Iec
| tested acc. to standard | IEC 60664-1, IEC 61984 |
|---|
Material Data
| Insulating material | PBT GF |
|---|---|
| Colour chart (similar) | RAL 2000 |
| Storage temperature, max. | 55 °C |
| Operating temperature, min. | -50 °C |
| Temperature range, installation, min. | -25 °C |
| Colour | orange |
|---|---|
| Storage temperature, min. | -25 °C |
| Max. relative humidity during storage | 80 % |
| Operating temperature, max. | 100 °C |
| Temperature range, installation, max. | 100 °C |
Classifications
| ETIM 6.0 | EC002943 |
|---|---|
| eClass 9.0 | 27-44-04-92 |
| eClass 10.0 | 27-44-04-92 |
| ETIM 7.0 | EC002943 |
|---|---|
| eClass 9.1 | 27-44-04-92 |
| UNSPSC | 30-21-18-01 |
Packing
| Packaging | Box |
|---|---|
| VPE width | 91 mm |
| VPE length | 39 mm |
|---|---|
| VPE height | 101 mm |
Notes
| IPC conformity | Conformity: The products are developed, manufactured and delivered according international recognized standards and norms and comply with the assured properties in the data sheet resp. fulfill decorative properties in accordance with IPC-A-610 "Class 2". Further claims on the products can be evaluated on request. |
|---|
