CA5-22ERT Auxiliary Contact Block
ABB

ABB CA5-22ERT CA5-22ERT Auxiliary Contact Block

  • MPN: CA5-22ERT
  • UPC: 662019821429
  • PPN: ABB-CA5-22ERT
  • UNSPSC: 39121522

CAD

$188.57

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

CA5-22ERT Auxiliary Contact Block

Specifications

Additional

Rated Insulation Voltage
690 V IEC, 600 V UL/CSA
Rated Operational Current AC-15 (Ie)
2 A (500 V, 690 V), 6 A (24/127 V), 4 A (220/240 V), 3 A (380/400 V)
Rated Frequency
50/60 Hz Auxiliary Circuit
Number of Poles
4
Number of Auxiliary Contacts NC
2
Weight
0.06 kg
Mounting Type
Front mounting
Material & Construction
Accessories for Block Contactors
Customs Tariff Number
85389099
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm), Business To Business
Rated Operational Voltage690 V Auxiliary Circuit
Rated Operational Current DC-13 (Ie)6 A / 144 W (24 V), 2.8 A / 134 W (48 V), 1 A / 72 W (72 V), 0.55 A / 60 W (110 V), 0.55 A / 69 W (125 V), 0.3 A / 66 W (220 V), 0.3 A / 75 W (250 V)
Rated Short-time Withstand Current (Icw)140 A for 0.1 s, 100 A for 1 s
Number of Auxiliary Contacts NO2
Product Dimensions47 mm (H) x 43 mm (W) x 39 mm (D)
Terminal TypeRing-Tongue Terminals
Degree of ProtectionAuxiliary Terminals IP10 (IEC 60529, IEC 60947-1, EN 60529)
ComplianceRoHS 2CMT2021-006277
Classification CodeseClass V11.0: 27371302, ETIM 9: EC000041, IDEA IGCC: 4743 (Auxiliary contact block), Object Classification Code: K
Suitable ForAF45, AF50, AF63, AF75, AF95, BG, A9, A16, A26, A45, A50, A63, A75, A95, A110, AL9, AL16, AL26, AE45, AE50, AE63, AE75, TAL9, TAL16, TAL26, TAE45, TAE50, TAE75, GA75, GAE75, UA50, UA63, UA75, UA95, UA110
