ABB CA5-31MRT CA5-31MRT Auxiliary Contact Block
- MPN: CA5-31MRT
- UPC: 662019404066
- PPN: ABB-CA5-31MRT
- UNSPSC: 39121522
CAD
$188.57
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CA5-31MRT Auxiliary Contact Block
Specifications
Additional
- Rated Operational Current AC-15 (Ie)
- (500 V) 2 A, (690 V) 2 A, (24/127 V) 6 A, (220/240 V) 4 A, (380/400 V) 3 A
- Rated Insulation Voltage (Ui)
- 690 V AC (IEC 60947-5-1), 600 V AC (UL/CSA)
- Rated Frequency
- 50 / 60 Hz (Auxiliary Circuit)
- Number of Auxiliary Contacts NO
- 3
- Number of Poles
- 4
- Mounting Type
- Front mounting
- Product Net Height
- 47 mm
- Product Net Depth / Length
- 39 mm
- Degree of Protection
- IP10 (IEC 60529, IEC 60947-1, EN 60529) Auxiliary Terminals
- Pilot Duty UL/CSA
- A600Q300
- Object Classification Code
- K
- ETIM 9 Classification
- EC000041 - Auxiliary contact block
Rated Operational Current DC-13 (Ie)(24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.30 A / 66 W, (250 V) 0.3 A / 75 W
Rated Operational VoltageAuxiliary Circuit 690 V
Rated Short-time Withstand Current Low Voltage (Icw)140 A for 0.1 s, 100 A for 1 s
Number of Auxiliary Contacts NC1
Terminal TypeRing-Tongue Terminals
Product Net Weight0.06 kg
Product Net Width43 mm
Material / ConstructionNot specified
ComplianceRoHS (2CMT2021-006277), WEEE Category 5 (Small Equipment)
Suitable ForModels: A9, A12, A16, A26, A30, A40, AL9, AL9Z, AL12, AL12Z, AL16, AL16Z, AL26, AL30, AL40, TAL9, TAL12, TAL16, TAL26, TAL30, TAL40
IDEA Granular Category Code (IGCC)4743 - Auxiliary contact block
Customs Tariff Number85389099
