ABB CA5-22M CA5-22M Auxiliary Contact Block
- MPN: CA5-22M
- UPC: 662019881362
- PPN: ABB-CA5-22M
- UNSPSC: 39121522
CAD
$138.52
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CA5-22M Auxiliary Contact Block
Specifications
Additional
| Number of Auxiliary Contacts NO | 2 |
|---|---|
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.30 A / 66 W, (250 V) 0.3 A / 75 W |
| Rated Insulation Voltage (Ui) | 690 V IEC 60947-5-1, 600 V UL/CSA |
| Minimum Switching Capacity | A9 ... A40-30-10 17 / 5 VLT4K |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Mechanical Durability | 10 million cycles |
| Product Net Height | 47 mm |
| Product Net Depth / Length | 39 mm |
| Mounting Type | Front mounting |
| Terminal Type | Screw Terminals |
| Compliance | RoHS 2CMT2021-006277 |
| Number of Auxiliary Contacts NC | 2 |
|---|---|
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A, (690 V) 2 A, (24/127 V) 6 A, (220/240 V) 4 A, (380/400 V) 3 A |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
| Maximum Electrical Switching Frequency | 1200 cycles per hour |
| Power Loss | 0.1 W per pole at rated operating conditions |
| Number of Poles | 4 |
| Product Net Width | 44 mm |
| Product Net Weight | 0.06 kg |
| Mounting Position | Front face |
| Material | Auxiliary Circuit - gG Type Fuses 10 A (Short-Circuit Protective Devices) |
