ABB CA5-31E CA5-31E Auxiliary Contact Block
- MPN: CA5-31E
- UPC: 662019881386
- PPN: ABB-CA5-31E
- UNSPSC: 39121522
CAD
$138.52
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CA5-31E Auxiliary Contact Block
Specifications
Additional
- Rated Operational Current AC-15 (Ie)
- (500 V) 2 A, (690 V) 2 A, (24/127 V) 6 A, (220/240 V) 4 A, (380/400 V) 3 A
- Rated Operational Voltage
- Auxiliary Circuit 690 V
- Pilot Duty UL/CSA
- A600Q300
- Maximum Electrical Switching Frequency
- 1200 cycles per hour
- Number of Poles
- 4
- Number of Auxiliary Contacts NC
- 1
- Product Net Height
- 47 mm
- Product Net Weight
- 0.06 kg
- Mounting Position
- Front face
- Material
- Not specified
- Short-Circuit Protective Devices
- Auxiliary Circuit - gG Type Fuses 10 A
- RoHS Information
- 2CMT2021-006277
- WEEE B2C / B2B
- Business To Business
- Brand
- Not specified
Rated Operational Current DC-13 (Ie)(24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.30 A / 66 W, (250 V) 0.3 A / 75 W
Rated Insulation Voltage (Ui)690 V acc. to IEC 60947-5-1; 600 V UL/CSA
Maximum Mechanical Switching Frequency3600 cycles per hour
Mechanical Durability10 million cycles
Number of Auxiliary Contacts NO3
Product Net Width43 mm
Product Net Depth / Length39 mm
Mounting TypeFront mounting
Terminal TypeScrew Terminals
Degree of ProtectionAuxiliary Terminals IP20 per IEC 60529, IEC 60947-1, EN 60529
Power Loss0.1 W per pole at rated operating conditions
WEEE Category5. Small Equipment (Max dimension 50 cm)
Country of OriginNot specified
Suitable ForAF45, AF50, AF63, AF75, AF95, BG, A9, A16, A26, A45, A50, A63, A75, A95, A110, AL9, AL16, AL26, AE45, AE50, AE63, AE75, TAL9, TAL16, TAL26, TAE45, TAE50, TAE75, GA75, GAE75, UA50, UA63, UA75, UA95, UA110
