CA5-22MRT Auxiliary Contact Block
ABB

ABB CA5-22MRT CA5-22MRT Auxiliary Contact Block

  • MPN: CA5-22MRT
  • UPC: 888614048942
  • PPN: ABB-CA5-22MRT
  • UNSPSC: 39121522

CAD

$188.57

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

CA5-22MRT Auxiliary Contact Block

Specifications

Additional

Rated Operational Voltage
Auxiliary Circuit 690 V
Rated Short-time Withstand Current
140 A for 0.1 s, 100 A for 1 s
Rated Operational Current DC-13 (Ie)
6 A / 144 W (24 V), 2.8 A / 134 W (48 V), 1 A / 72 W (72 V), 0.55 A / 60 W (110 V), 0.55 A / 69 W (125 V), 0.30 A / 66 W (220 V), 0.3 A / 75 W (250 V)
Product Net Length
39 mm
Product Net Height
47 mm
Mounting Type
Front mounting
Material
Accessories for Block Contactors
Number of Auxiliary Contacts NC
2
RoHS Information
2CMT2021-006277
Customs Tariff Number
85389099
WEEE B2C / B2B
Business To Business
IDEA Granular Category Code (IGCC)
4743 - Auxiliary contact block
Suitable For
A9, A12, A16, A26, A30, A40, AL9, AL9Z, AL12, AL12Z, AL16, AL16Z, AL26, AL30, AL40, TAL9, TAL12, TAL16, TAL26, TAL30, TAL40
Product Main Type
Accessories for Block Contactors
Rated FrequencyAuxiliary Circuit 50 / 60 Hz
Rated Operational Current AC-15 (Ie)2 A (500 V), 2 A (690 V), 6 A (24/127 V), 4 A (220/240 V), 3 A (380/400 V)
Number of Poles4
Product Net Width43 mm
Product Net Weight0.06 kg
Terminal TypeRing-Tongue Terminals
Degree of ProtectionIP10 (IEC 60529, IEC 60947-1, EN 60529) Auxiliary Terminals
Number of Auxiliary Contacts NO2
Object Classification CodeK
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
ETIM 9EC000041 - Auxiliary contact block
eClassV11.0 : 27371302
Pilot Duty UL/CSAA600Q300
