ABB CA5-31M CA5-31M Auxiliary Contact Block
- MPN: CA5-31M
- UPC: 662019881393
- PPN: ABB-CA5-31M
- UNSPSC: 39121522
CAD
$138.52
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
CA5-31M Auxiliary Contact Block
Specifications
Additional
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A, (690 V) 2 A, (24 / 127 V) 6 A, (220 / 240 V) 4 A, (380 / 400 V) 3 A |
|---|---|
| Maximum Electrical Switching Frequency | 1200 cycles per hour |
| Rated Short-time Withstand Current Low Voltage (Icw) | 140 A for 0.1 s, 100 A for 1 s |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
| Number of Poles | 4 |
| Number of Auxiliary Contacts NC | 1 |
| Terminal Type | Screw Terminals |
| Mounting Position | Front face |
| Product Net Width | 43 mm |
| Product Net Weight | 0.06 kg |
| Short-Circuit Protective Devices | Auxiliary Circuit - gG Type Fuses 10 A |
| Pilot Duty UL/CSA | A600 Q300 |
| eClass | V11.0 : 27371302 |
| WEEE B2C / B2B | Business To Business |
| Customs Tariff Number | 85389099 |
| Suitable For | A9, A12, A16, A26, A30, A40, AL9, AL9Z, AL12, AL12Z, AL16, AL16Z, AL26, AL30, AL40, TAL9, TAL12, TAL16, TAL26, TAL30, TAL40, UA16, UA26, UA30 |
| Object Classification Code | K |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (125 V) 0.55 A / 69 W, (220 V) 0.30 A / 66 W, (250 V) 0.3 A / 75 W |
|---|---|
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Rated Insulation Voltage (Ui) | 690 V AC (IEC 60947-5-1), 600 V (UL/CSA) |
| Mechanical Durability | 10 million cycles |
| Number of Auxiliary Contacts NO | 3 |
| Power Loss | 0.1 W per pole at rated operating conditions |
| Mounting Type | Front mounting |
| Product Net Height | 47 mm |
| Product Net Depth / Length | 39 mm |
| Degree of Protection | IP20 (IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals) |
| Rated Frequency | 50 / 60 Hz (Auxiliary Circuit) |
| RoHS Information | 2CMT2021-006277 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| E-Number (Finland) | 3709190 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
| Minimum Switching Capacity | A9 ... A40-30-10 17 / 5 VLT4K |
