Square D P29393 Circuit breaker accessory, PowerPacT H/J/L, shunt trip, 125VDC
- MPN: P29393
- PPN: SCH-P29393
CAD
$1333.18
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This shunt trip unit is one of the available accessories for PowerPacT H/J/L circuit breakers. Trip units provide remote trip capability energized from a separate voltage source. This shunt trip unit requires 125VDC to energize trip coils and operate. Spring clamp connections make for easy installation. The units meet UL and CSA standards.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | United States |
|---|
Complementary Attributes
| Rated Voltage | 125-125 V DC |
|---|
Important Information Attributes
| Persona Type Ids | LC, OM, OM8, PB |
|---|---|
| Market Segmentation Id | COMMERCIAL, INDUSTRIAL |
| Range Of Product | PowerPact H, PowerPact J, PowerPact L |
| Local Publishable Date | 2025-11-13 |
| Stocking Flag | Y |
| Serviceability | No |
| Field Service Division | PPIBS |
| Weee Product Category | 5 |
| Rohs Eur In Scope | Yes |
| Rohs Eur Conformity Date | 1807 |
| China Rohs In Scope | No |
| Without Single Use Plastic | No |
| Tier Id | 1 |
| Function Option Id | STANDARD |
| Product Kit Identifier | N |
| Product Availability | Stock - Normally stocked in distribution facility |
| Returnability | No |
| Tightening Torque | 1.4-1.4 N.m 0.82-2.5 mm² (18 AWG...14 AWG) |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8505907501 |
| Persona Type Names | Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder |
|---|---|
| Market Segmentation | Commercial, Industrial |
| Local Data Status | Publishable |
| Return Indicator | N |
| Stock Policy | 2 |
| Traceability | No |
| Weee Scope | In |
| Scope Perimeter | Outside of Europe |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Standard |
| Energy Efficiency Optimized | False |
| Product Or Component Type | shunt trip |
| Sustainable Packaging | No |
| Certificate Agency | CSA |
| Package Weight(Lbs) | 0.132 kg |
| Warranty (In Months) | 18 |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information. |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | No |
| Take Back | No |
|---|---|
| Mercury Free | Yes |
| Packaging Made With Recycled Cardboard | Yes |
General Attributes
| Range Of Product | PowerPact H, PowerPact J, PowerPact L |
|---|
| Product Or Component Type | shunt trip |
|---|
