Square D P29394 Circuit breaker accessory, PowerPacT H/J/L, shunt trip, 250VDC
- MPN: P29394
- PPN: SCH-P29394
CAD
$1333.18
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This shunt trip unit is one of the available accessories for PowerPacT H/J/L circuit breakers. Trip units provide remote trip capability energized from a separate voltage source. This shunt trip unit requires 250VDC to energize trip coils and operate. Spring clamp connections make for easy installation. The units meet UL and CSA standards.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
Complementary Attributes
- Rated Voltage
- 250-250 V DC
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Range Of Product
- PowerPact H, PowerPact J, PowerPact L
- Local Publishable Date
- 2025-11-13
- Stocking Flag
- Y
- Serviceability
- No
- Field Service Division
- PPIBS
- Weee Product Category
- 5
- Rohs Eur In Scope
- Yes
- Rohs Eur Conformity Date
- 1807
- China Rohs In Scope
- No
- Without Single Use Plastic
- No
- Tier Id
- 1
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Returnability
- No
- Tightening Torque
- 1.4-1.4 N.m 0.82-2.5 mm² (18 AWG...14 AWG)
- Nbr. Of Units In Pkg.
- 1
- Take-back
- No
- Customs Code
- 8505907501
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
Local Data StatusPublishable
Return IndicatorN
Stock Policy1
TraceabilityNo
Weee ScopeIn
Scope PerimeterOutside of Europe
Rohs Eur StatusCompliant
Rohs Eur Full Compliance StatusCompliant
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier1
Function OptionStandard
Energy Efficiency OptimizedFalse
Product Or Component Typeshunt trip
Sustainable PackagingNo
Certificate AgencyCSA
Package Weight(Lbs)0.454 kg
Warranty (In Months)18
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Eu Rohs Directive
- Compliant
- Packaging Without Single Use Plastic
- No
Take BackNo
Mercury FreeYes
Packaging Made With Recycled CardboardYes
General Attributes
- Range Of Product
- PowerPact H, PowerPact J, PowerPact L
Product Or Component Typeshunt trip
