PMA VOHG-17S.30 Heavy Duty Conduit
- MPN: VOHG-17S.30
- UPC: 786209977243
- PPN: T-B-VOHG-17S.30
CAD
$428.00
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Fine Profile Very Heavy Wall Pliable Gray Conduit, (VOH) Material - Polyamide 6, Conduit Size NW - 17, 30 Meters
Features
- Robust construction
- High degree of mechanical protection
- Outstanding pull-out resistance
- Self-extinguishing
- Free from halogens and cadmium
- Renewable Energy
- Exterior machine connections, for heavy machine equipment
Specifications
European Specifications (ETIM)
| ETIM | EC001175 Corrugated plastic hose |
|---|---|
| Outer diameter | 21mm |
| Material | Polyamide 6 |
| Operating temperature | -40 - +105°C |
| UV resistant | Y |
| Sheathing material | Not sheathed |
| Lengthwise slotted | N |
| Halogen free | Y |
| Approved according to UR | N |
| Approved according to LUL/British Standard | N |
| Approved according to UTAC | N |
| Approved according to NF F 16-101 | N |
| Nominal diameter | 20mm |
|---|---|
| Inner diameter | 14.5mm |
| Compressive strength | 600N |
| Fire resistance in accordance with UL94 | V0 |
| Colour | Grey |
| Bending strength | Flexible |
| Closable (two-part) | N |
| Approved according to DIN EN 61386-23 | N |
| Approved according to CSA | N |
| Approved according to Lloyd's Register TA | N |
| Approved according to DIN 5510 | N |
Packaging
| Inner Quantity | 1 |
|---|---|
| Outer Dimensions (inches) | 47.244x31.496x30.709 |
| Outer Quantity | 20 |
|---|---|
| Weight Uom | 0.12 lbs. Each |
North American Specifications (UNSPSC)
| UNSPSC | 39131706 Electrical conduit |
|---|---|
| Brand Name | PMA |
| Application | Machine |
| Outside Diameter | 0.83 Inch |
| Flexibility | Pliable |
| Color | Gray |
| IGCC | 5535 Electrical conduit |
|---|---|
| Type | Heavy Duty Conduit |
| Trade Size | NW17 |
| Length | 30 m |
| Material | Polyamide/Nylon 6 |
