Square D AL400LA Aluminum Lug Kit for PowerPact LA/LH/Q4 Circuit Breakers, 400A, 1.26 Inch Depth, 1.26 Inch Width

MPN: AL400LA
UPC: 785901368236
PPN: SCH-AL400LA
UNSPSC: 39121601

$62.72

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This lug kit is a connector accessory for PowerPact LA, LH, Q4 circuit breakers. This is an aluminum lug kit. This accessory has a rated current of 400 amps. The lug kit are for terminal connection and will accept a wire size of AWG 1 with a 600 kcmil. This product complies with UL standards. This lug can be used only on standard circuit breakers. This lug has a tightening torque of 42-42 Nm, with a cable cross section 42-300 mm².

Features

Aluminum mechanical lugs kit 125 to 400A rated, for use with LA, LH, Q4 molded case circuit breakers, 1 piece per kit
Lugs are made of tin-plated aluminum which allows to use them with aluminum and Copper conductors
Mechanical lugs are for use with unit mount LA, LH, Q4 molded case circuit breakers for line, load sides
Terminal data for this lugs is (1) 1 AWG–600 kcmil or (2) 1 AWG–250 kcmil aluminum or copper
All lugs are UL Listed and CSA certified for their proper application

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	United States

Depth	1.26 in

Important Information Attributes

Persona Type Ids	LC, OM, OM8, PB
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Tightening Torque	42-42 N.m 42-300 mm² (1 AWG...600 kcmil), 42-42 N.m 42-127 mm² (1 AWG...250 kcmil)
Local Publishable Date	2026-08-27
Serviceability	No
Field Service Division	PPIBS
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	3
Function Option	Standard
Energy Efficiency Optimized	False
Returnability	Yes
Height Nominal	2.01 in
Nbr. Of Units In Pkg.	1
Warranty In Months	18

Persona Type Names	Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market Segmentation	Commercial, Industrial
Local Data Status	Publishable
Return Indicator	Y
Traceability	No
Weee Scope	Out
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	2542
China Rohs In Scope	No
Without Single Use Plastic	No
Tier Id	3
Function Option Id	STANDARD
Product Kit Identifier	N
Product Availability	Stock - Normally stocked in distribution facility
Sustainable Packaging	No
Width Nominal	1.26 in
Customs Code	8536904000

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
Recycled Metal Content At Cr Level	0 %
Eu Rohs Directive	Compliant By Exemption
Packaging Without Single Use Plastic	No

Take Back	No
Mercury Free	Yes
Packaging Made With Recycled Cardboard	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
