Schneider Electric XEND2611 Harmony XAC Double Contact Block 2NO 10A Front Mounting
- MPN: XEND2611
- PPN: SCH-XEND2611
- UNSPSC: 39121522
CAD
$196.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Designed for seamless integration within automation and control systems, this double contact block from Schneider Electric features two normally open (2NO) configurations, ensuring reliable performance for various applications. With a robust 10A capacity, it is suitable for front mounting, making it an ideal choice when space and efficiency are priorities. As part of the Harmony series, it exemplifies quality engineering and innovation, ensuring that it can withstand the demands of modern control environments while facilitating effective interaction within pilot devices.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Czechia |
|---|
| Weight | 115 g |
|---|
Complementary Attributes
| Maximum Resistance Across Terminals | 25 MOhm |
|---|---|
| Rated Operational Power In W | 31 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C35 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C48 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C |
| Uimp Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
| Rated Operational Power In Va | 140 VA AC-15 1000000 cycles 60 cyc/mn 24 V 50/60 Hz 0.5 inductive210 VA AC-15 1000000 cycles 60 cyc/mn 48 V 50/60 Hz 0.5 inductive640 VA AC-15 1000000 cycles 60 cyc/mn 127 V 50/60 Hz 0.5 inductive680 VA AC-15 1000000 cycles 60 cyc/mn 230 V 50/60 Hz 0.5 inductive |
|---|---|
| Ui Rated Insulation Voltage | 400 V 3)IEC 60947-1 |
Important Information Attributes
| Persona Type Ids | BM9, EU, LC, OM, OM8, PB, SC, SI, VR |
|---|---|
| Market Segmentation Id | COMMERCIAL, INDUSTRIAL |
| Contact Operation | simultaneous, slow-break |
| Connections Terminals | screw clamp terminals, 1 x 2.5 mm² with or without cable end, screw clamp terminals, 2 x 1.5 mm² with or without cable end |
| Terminals Description Iso N°1 | (23-24)NO, (13-14)NO, (23-24)NO, B, (13-14)NO |
| Carbon Footprint Of The Distribution Phase A4 | 0.0812154602094831, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase A5 | 0.010840908176288936, 0 kg CO2 eq. |
| Carbon Footprint Of The Use Phase B2 B3 B4 B6 | kg CO2 eq., 0 |
| Local Publishable Date | 2026-01-12 |
| Weee Scope | In |
| Scope Perimeter | At least in Europe |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | No |
| Tier Id | 2 |
| Function Option Id | STANDARD |
| Product Kit Identifier | N |
| Contact Block Application | single speed |
| Contact Code Designation | A300 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix AQ300 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A |
| Electrical Circuit Type | control circuit |
| Mechanical Interlocking | with mechanical interlocking |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Range Of Product | Harmony XAC |
| Shock Resistance | 100 gn IEC 60068-2-27 |
| Sustainable Packaging | No |
| Type Of Operator | 2 spring return |
| Weee Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Data Source | extrapolated product |
| Customs Code | 8536509065 |
| Short Circuit Protection | 10 A fuse protection cartridge gG |
| Functional Unit Description | This contact block allows fast and easy replacement and configuration of your push buttons and selector switches. It is easily installed and replaced on XACM and XACB pendant control stations and connects to control circuits with simple screw-clamp connections. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. |
| Functional Unit Unit | unit |
| Recyclability Potential In % | 46 |
| Persona Type Names | Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner |
|---|---|
| Market Segmentation | Commercial, Industrial |
| Terminal Identifier | (11-12)NC, (13-14)NO, (11-12)NC, (13-14)NO |
| Certificate Agency | IEC 60947-5-1, CSA C22.2 No 14 |
| Terminals Description Iso N°2 | (33-34)NO, (43-44)NO, B, (33-34)NO, (43-44)NO |
| Carbon Footprint Of The End Of Life Phase C1 To C4 | 0.2 kg CO2 eq., 0.2195194430438938 |
| Carbon Footprint Of The Manufacturing Phase A1 To A3 | 0.8 kg CO2 eq., 0.7725937084540949 |
| Local Data Status | Publishable |
| Return Indicator | Y |
| Weee Product Category | 5 |
| Eoli Availability Display | No need of specific recycling operations |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 1930 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 2 |
| Function Option | Standard |
| Component Name | XEND |
| Contact Block Type | double |
| Contacts Type And Composition | 2 NO |
| Mechanical Durability | 1000000 cycles |
| Mounting Of Block | front mounting |
| Product Or Component Type | contact block |
| Returnability | Yes |
| Software Version | v6.3.0.1-4 |
| Total Lifecycle Carbon Footprint | 1 kg CO2 eq. |
| Vibration Resistance | 15 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Database Version | 2024-01 |
| Nbr. Of Units In Pkg. | 1 |
| Ithe Conventional Enclosed Thermal Current | 10 A |
| Warranty In Months | 18 |
| Functional Unit Quantity | 1 |
| Reference Lifetime In Y | 20 |
Environment Attributes Main
| Ambient Air Temperature For Operation | -25-70 °C, -25-70 °C |
|---|---|
| Product Compatibility | XACM, XACB |
| Reach Free Shvc | Yes |
| China Rohs Regulation | X |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP2506031EN |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Free Of Svhc | Yes |
| Pep Code | ENVPEP2506031EN |
| Pcr Version | PEP-PCR-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Ambient Air Temperature For Storage | -40-70 °C, -40-70 °C |
|---|---|
| Take Back | No |
| Recycled Metal Content At Cr Level | 0 % |
| Toxic Heavy Metal Free | Yes |
| Carbon Footprint | 1.0841695198837606 |
| Eu Rohs Directive | Compliant |
| Packaging Without Single Use Plastic | No |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Pep Verification Date | 2025-06-30 |
| Psr Version | PSR-0005-ed3.1-EN-2023 12 08 |
General Attributes
| Product Or Component Type | contact block |
|---|
| Range Of Product | Harmony XAC |
|---|
ETIM
| ETIM 8 | EC000041 |
|---|---|
| ETIM 10 | EC000041 |
| ETIM 9 | EC000041 |
|---|
Contractual Warranty Attributes
| Warranty Period | 18 months |
|---|
| Warranty | 18 months |
|---|
