Schneider Electric LA1DX11 TeSys Deca Auxiliary Contact Block 1NO+1NC, IP2X, 0.1A, Front Mounting
- MPN: LA1DX11
- PPN: SCH-LA1DX11
- UNSPSC: 39121522
CAD
$294.49
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments. It provides 1NO + 1NC protected contacts rated up to 0.1A 125V AC / 30V DC, connection by screw clamp terminals. Very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Features
- Meet the need for more and various tpye control contact of TeSys Deca contactor and control relay
- Easy choice for simple applications
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Czechia |
|---|---|
| Depth | 39 mm |
| Weight | 45 g |
|---|
Complementary Attributes
| Minimum Switching Current | 1 mA |
|---|---|
| Ie Rated Operational Current | 0.1 A |
| Ui Rated Insulation Voltage | 250 V IEC 60947-5-1 |
| Minimum Switching Voltage | 5 V |
|---|---|
| Ue Rated Operational Voltage | 125 V AC protected contact30 V DC protected contact |
Important Information Attributes
| Persona Type Ids | EU, LC, OM, OM8, PB, SI |
|---|---|
| Market Segmentation Id | COMMERCIAL, INDUSTRIAL |
| Tightening Torque | 1.7 N.m flat Ø 6 mm, 1.7 N.m Philips No 2, 1.7 N.m pozidriv No 2 |
| Certificate Agency | CB, UL, CSA, CCC, EAC, UKCA |
| Carbon Footprint Of The End Of Life Phase C1 To C4 | 0.1 kg CO2 eq., 0.12651077858685408 |
| Carbon Footprint Of The Manufacturing Phase A1 To A3 | 0.3 kg CO2 eq., 0.3417697496472613 |
| Local Data Status | Publishable |
| Return Indicator | N |
| Traceability | No |
| Use Carbon Footprint | 1.5803 |
| Weee Product Category | 5 |
| Reach Full Compliance Status | Free of Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Free of Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant |
| Rohs Eur Full Compliance Status | Compliant |
| China Rohs Label | 1 |
| Without Single Use Plastic | Yes |
| Tier Id | 1 |
| Function Option Id | STANDARD |
| Product Kit Identifier | N |
| Device Short Name | LA1 |
| Environmental Characteristic | harsh environment |
| Mechanical Durability | 5 Mcycles |
| Pole Contact Composition | 1 NO (sealed) + 1 NC (sealed) |
| Product Name | TeSys Deca |
| Protective Treatment | TH IEC 60068 |
| Range Of Product | TeSys Deca |
| Shielding Continuity Terminal | without |
| Sustainable Packaging | Yes |
| Weee Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Database Version | 2022-01 |
| Height Nominal | 48 mm |
| Nbr. Of Units In Pkg. | 1 |
| Warranty In Months | 18 |
| Functional Unit Quantity | 1 |
| Reference Lifetime In Y | 20 |
| Persona Type Names | End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator |
|---|---|
| Market Segmentation | Commercial, Industrial |
| Connections Terminals | screw clamp terminals 2 1-2.5 mm²flexible without cable endscrew clamp terminals 2 1-2.5 mm²rigidscrew clamp terminals 1 1-2.5 mm²flexible with cable end, screw clamp terminals 1 1-2.5 mm²flexible without cable end, screw clamp terminals 2 1-2.5 mm²flexible with cable end, screw clamp terminals 1 1-2.5 mm²rigid |
| Carbon Footprint Of The Distribution Phase A4 | 0.05552661309576669, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase A5 | 0.006938776277465732, 0 kg CO2 eq. |
| Carbon Footprint Of The Use Phase B2 B3 B4 B6 | 2 kg CO2 eq., 1.5803 |
| Local Publishable Date | 2026-07-16 |
| Serviceability | No |
| Field Service Division | PPIBS |
| Weee Scope | In |
| Scope Perimeter | At least in Europe |
| Reach Full Compliance Status Id | NOT_CONTAINING_SVHC |
| Rohs Eur In Scope | Yes |
| Rohs Eur Conformity Date | 1929 |
| China Rohs In Scope | No |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Standard |
| Compatibility Code | LA1 |
| Energy Efficiency Optimized | False |
| Insulation Resistance | > 10 MOhm> 10 MOhm |
| Mounting Location | front |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Product Or Component Type | auxiliary contact block |
| Range | TeSys |
| Returnability | No |
| Software Version | v5.9.4 |
| Total Lifecycle Carbon Footprint | 2 kg CO2 eq. |
| Pole Contact Comp | 1 NO (sealed) + 1 NC (sealed) |
| Data Source | extrapolated product |
| Width Nominal | 44 mm |
| Customs Code | 8536509065 |
| Functional Unit Description | To add instantaneous auxiliary contact blocks in front face on TeSys k contactors as NO and NC contacts for 20 years. |
| Functional Unit Unit | unit |
| Recyclability Potential In % | 39 |
Environment Attributes Main
| China Rohs Regulation | Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope) |
|---|---|
| Ambient Air Temperature For Storage | -25-70 °C, -25-70 °C |
| Reach Free Shvc | Yes |
| Toxic Heavy Metal Free | Yes |
| Carbon Footprint | 2.1110459176073477 |
| Ip Degree Of Protection | IP2X conforming to IEC 60529 |
| Packaging Without Single Use Plastic | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Pcr Version | PEP-PCR-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Ambient Air Temperature For Operation | -25-70 °C, -25-70 °C |
|---|---|
| Take Back | No |
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Eu Rohs Directive | Compliant |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Free Of Svhc | Yes |
| Pep Verification Date | 2025-06-17 |
| Psr Version | PSR-0005-ed2-2016 03 29 |
General Attributes
| Product Or Component Type | auxiliary contact block |
|---|
| Range Of Product | TeSys Deca |
|---|
ETIM
| ETIM 8 | EC000041 |
|---|---|
| ETIM 10 | EC000041 |
| ETIM 9 | EC000041 |
|---|
