Hubbell

Hubbell BBB424UD Copper Busbar 1/4 Inch x 4 Inch x 24 Inch, Bare Copper, Undrilled

Copper Busbar 1/4 Inch x 4 Inch x 24 Inch, Bare Copper, Undrilled
  • MPN: BBB424UD
  • UPC: 781810489451
  • PPN: BUR-BBB424UD
  • UNSPSC: 39121117

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$818.66/ EA

Description

Copper BusBar, 24 in L, Can be used as a common ground point and power applications.

Features

  • Bare Copper Busbar
  • UL Listed for Grounding
  • Many sizes and hole patterns available

Specifications

Specifications

Buy American Compliant
Contact Manufacturer
Dimension - Bar Thickness inch
0.25 in
Dimension - Width fraction
4 in
Width
4.00 in
Physical Attribute - Number of Holes
0
Standards - RoHS Compliance Status
CM
Sub Brand
BUS BAR
ARRA Compliant
Yes
Class Code
B41
Freight Class Code
16027000
Image Actual Or Representative
A
MSDS Flag
No
Replaced Catalog Number
10104614
Sub Class Code
B41BDLF
Base Unit of Measure
EA
Carton - Gross Weight per Pack
10.700 lb.
Carton - Pack Description
Carton
Carton - Total Units
1
Each - Number of Sub Packs
1
Lowest Level UOM
Each
Package Quantity
1 EA
Pallet Height
47.375 in
Pallet Weight
1008.000 lb.
Standard Package Quantity
1
Country of OriginUS
Dimension - Bar Thickness mm6 mm
Dimension - Width inch4.00 in
Each - Width4.00 in
Product TypeMechanical
ApplicationFor Used As A Common Ground Point And Power Applications
TypeBBB, Undrilled
Certification AgencyProposition 65
Description - InvoiceBUSBAR1/4X4X24UNDRILLED
Harmonization Code8536908585
Lead Time12 wk
Order Multiple1 EA
Stock IndicatorN - Non-stock
MaterialCopper
BOX SIZE4.625x24.313x7.313 (in)
Carton - Number of Sub Packs1
Carton - SCC-14 Next Lower Level Sub Pack00781810489451
Case - SCC-14 Next Lower Level Sub Pack30781810489452
Each - Pack DescriptionEach
Package - GTIN - Package30781810489452
Pallet - GTIN - Package70781810489450
Pallet Length48.000 in
Pallet Width40.000 in

Certifications

CSA Approved
No
UL Recognized
No
cULusYes
EU RoHS IndicatorYes
