Homac 2042-14 COPPER SECONDARY STUD ADAPTER
Homac 2042-14 COPPER SECONDARY STUD ADAPTER
- MPN: 2042-14
- UPC: 783786859009
- PPN: T-B-2042-14
- UNSPSC: 39121443
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$458.70/ EA
Description
Copper Tin-Plated Threaded Transformer Stud Adapter for NEMA pad-style connections - Ten-hole transformer stud adapters, Silver Brazed Stud - Size 1-1/4 inch 12 threads UNF-2B with 1.5 inch Outside Diameter. Pad 8.625 inch long x 3 inch wide x .25 inch thick. 2 rows of 5 holes spaced 1.75 inch on center and .562 inch Diameter.
Specifications
Ordering
- Country of Origin
- United States (US)
Selling Unit of Measureeach
Additional Information
- Application
- NEMA Pad-Style Connections
- Connection Type
- Threaded
- Insulation Material
- None
- Product Name
- ELECTRICAL CONNECTOR,<1000V
- Size
- Pad 8.625 inch long x 3 inch wide x .25 inch thick
- Surface Finishing
- Tin Plated
Brand / LabelHomac
Effective Date20091104
MaterialCopper
Product TypeThreaded Transformer Adapter - Stud to Flat
Special FunctionsNEMA Spacing of 1.75 inch Centers. 1-1/4 inch Stud
Classifications
- WEEE Category
- Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)4663 >> Electrical underground bus connector
