Burndy

Burndy YA27L2NT38 Copper Terminal Connector, 3/0 AWG, 3/8 Inch Stud, 0.62 Inch OD, Tin Plated

  • MPN: YA27L2NT38
  • UPC: 781810498071
  • PPN: BUR-10108458

CAD

$59.82

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Copper Tubing,Narrow,Double Hole /W/ insp window,3/0 AWG,3/8"stud, Tin plated,Orange,14 index

Documentation & Downloads

Specifications

Dimensions

Dimension - B Length fraction1 in
Dimension - Bolt Hole Size inch0.39 in
Dimension - D inch1.74 in
Dimension - Length Overall inch3.30 in
Dimension - Outside Diameter inch0.62 in
Dimension - Strip Length inch1-1/16
Physical Attribute - Tongue AngleStraight
Dimension - B Length inch1.00 in
Dimension - Bolt Size fraction3/8
Dimension - L Length Overall mm84 mm
Dimension - N inch0.41 in
Dimension - Pad Width inch0.60 in
Dimension - Stud Size inch3/8

Certifications and Compliance

Certification - CSA ApprovedYes
Certification - UL RecognizedNo
Standards - RoHS Compliance StatusCM
Certification - ETLNo
Certification - cULusNo
UL ListedYes

Conductor Related

Conductor - Copper DLO Size RangeN/A
Conductor - Copper Str Size3/0 AWG
Conductor - Copper Solid Size3/0 AWG

General

Color CodeOrange
Die Index14
MaterialCopper
PlatedY
Trade NameHYLUG™
Connector TypeTerminal
Feature - Barrel TypeStandard
Physical Attribute - Number of Holes2
Plating TypeTin - Electro Plated
UPC781810498071

Electrical Ratings

Rating - KVA35 kV
Voltage - Maximum35000
Rating - Minimum Voltage600

Logistics

Minimum Pack Quantity1
Copper Terminal Connector, 3/0 AWG, 3/8 Inch Stud, 0.62 Inch OD, Tin Plated
