Mersen A1018624 Protistor 22x58 gR Fuse 32A 690V, Silver-Plated Copper
- MPN: A1018624
- PPN: FER-A1018624
CAD
$207.95
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
These Protistor® size 22x58 have been designed to protect power semiconductors, complying with standard IEC 60269-1 and -4. They are extremely high interrupting rating fuses: 690 VAC, with large band of ratings (current rating 15 to 135 A). Two models are existing: with or without trip-indicator
Specifications
Key Specifications
- Rated voltage AC IEC
- 690 V
- ROHS Compliant
- Yes
- Speed/Characteristic
- gR
- Mounting
- Clip
- Melting I2t
- 77.4 A²s
- Indication System
- Yes
- Connection/Terminal Material
- Silver-Plated Copper
- Body/Insulating Material
- Ceramic
- Length
- 2.28 in
Ampere Rating32 A
AC or DCAC
Fuse Size22x58
Clearing I2t At Rated Voltage670 A²s
AC Max I.R./Breaking Capacity: I1160 kA
Indication System TypeStriker
Connection/Terminal TypeFerrule
Power Dissipation at Rated Current Value9.1 W
Weight0.132 lb
