Mersen Y1018622 Protistor Fuse 22x58 Inch 20 A 690 VAC gR Class with Trip Indicator
- MPN: Y1018622
- PPN: FER-Y1018622
CAD
$217.26
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
These Protistor® size 22x58 have been designed to protect power semiconductors, complying with standard IEC 60269-1 and -4. They are extremely high interrupting rating fuses: 690 VAC, with large band of ratings (current rating 15 to 135 A). Two models are existing: with or without trip-indicator
Specifications
Key Specifications
- Rated voltage AC IEC
- 690 V
- ROHS Compliant
- Yes
- Speed/Characteristic
- gR
- Mounting
- Clip
- Melting I2t
- 17.1 A²s
- Indication System
- Yes
- Connection/Terminal Material
- Silver-Plated Copper
- Body/Insulating Material
- Ceramic
- Length
- 2.28 in
Ampere Rating20 A
AC or DCAC
Fuse Size22x58
Clearing I2t At Rated Voltage160 A²s
AC Max I.R./Breaking Capacity: I1160 kA
Indication System TypeStriker
Connection/Terminal TypeFerrule
Power Dissipation at Rated Current Value7 W
Weight0.132 lb
