Blackburn PTC 350 Tapered Compression Splice

Tapered Compression Splice

Blackburn PTC 350 Tapered Compression Splice

MPN: PTC 350
UPC: 783786742141
PPN: T-B-PTC 350

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$179.42/ EA

Loading add to cart quantity...

Description

Copper Tin-Plated Tapered Splices - solid center oil stop, wire size 350

Features

Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop.
Tapered Ends Enable use in High-Voltage Installations up to 69kV.
Tin Plated to Resist Corrosion and Extend Shelf Life.
PTC Series Features a Solid Center that Prevents Oil Seepage.

Specifications

North American Specifications (UNSPSC)

UNSPSC: 39121449 Wire or cable compression splice

Brand Name: Blackburn

Special Features: Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop. Tapered Ends Enable use in High-Voltage Installations up to 69 kV. Tin-Plated to Resist Corrosion and Extend Shelf Life. Solid Center that Prevents Oil Seepage.

Size: Length 2-25/32 inches

Conductor Range: 350

Material: Copper

Insulation: No

IGCC4669 Wire or cable compression splice

TypeTapered Compression Splice

ApplicationHigh Voltage, Oil, Harsh Enviroments

ConnectionCompression

Number Of Conductors2

FinishTin-Plated

Environmental ConditionsHarsh Environments

Packaging

Outer Quantity: 50

Weight Uom: 22.38 lbs. per 100

Outer Dimensions (inches)7.8x6.9x4.6
