Blackburn PTC 500 Tapered Compression Splice 500 MCM, 3-17/32 Inch, Copper, Tin-Plated, 69kV
Blackburn PTC 500 Tapered Compression Splice 500 MCM, 3-17/32 Inch, Copper, Tin-Plated, 69kV
- MPN: PTC 500
- PPN: T-B-PTC 500
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$263.71/ EA
Description
Copper Tin-Plated Tapered Splices - solid center oil stop, wire size 500
Features
- Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop.
- Tapered Ends Enable use in High-Voltage Installations up to 69kV.
- Tin Plated to Resist Corrosion and Extend Shelf Life.
- PTC Series Features a Solid Center that Prevents Oil Seepage.
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 39121449 Wire or cable compression splice
- Brand Name
- Blackburn
- Special Features
- Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop. Tapered Ends Enable use in High-Voltage Installations up to 69 kV. Tin-Plated to Resist Corrosion and Extend Shelf Life. Solid Center that Prevents Oil Seepage.
- Size
- Length 3-17/32 inches
- Conductor Range
- 500
- Material
- Copper
- Insulation
- No
IGCC4669 Wire or cable compression splice
TypeTapered Compression Splice
ApplicationHigh Voltage, Oil, Harsh Enviroments
ConnectionCompression
Number Of Conductors2
FinishTin-Plated
Environmental ConditionsHarsh Environments
Packaging
- Outer Quantity
- 25
- Weight Uom
- 0.17 lbs. Each
Outer Dimensions (inches)7.25x6.5x4
