Blackburn PTC 750 Copper Tapered Compression Splice, 750 Wire Size, 4-7/32 Inch Length
- MPN: PTC 750
- UPC: 078378674222
- PPN: T-B-PTC 750
CAD
$435.39
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Copper Tin-Plated Tapered Splices - solid center oil stop, wire size 750
Features
- Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop.
- Tapered Ends Enable use in High-Voltage Installations up to 69kV.
- Tin Plated to Resist Corrosion and Extend Shelf Life.
- PTC Series Features a Solid Center that Prevents Oil Seepage.
Documentation & Downloads
Specifications
Packaging
- Outer Quantity
- 25
- Weight Uom
- 0.69 lbs. Each
Outer Dimensions (inches)1x1x1
North American Specifications (UNSPSC)
- UNSPSC
- 39121449 Wire or cable compression splice
- Brand Name
- Blackburn
- Special Features
- Made from Electrolytic Seamless Copper Tubing for High Conductivity and Minimal Voltage Drop. Tapered Ends Enable use in High-Voltage Installations up to 69 kV. Tin-Plated to Resist Corrosion and Extend Shelf Life. Solid Center that Prevents Oil Seepage.
- Size
- Length 4-7/32 inches
- Conductor Range
- 750
- Material
- Copper
- Insulation
- No
IGCC4669 Wire or cable compression splice
TypeTapered Compression Splice
ApplicationHigh Voltage, Oil, Harsh Enviroments
ConnectionCompression
Number Of Conductors2
FinishTin-Plated
Environmental ConditionsHarsh Environments
