Square D PCSPCT190X5000 AccuSine+ Isolation Transformer 5/5 600V AC 1.8kg
Square D PCSPCT190X5000 AccuSine+ Isolation Transformer 5/5 600V AC 1.8kg
- MPN: PCSPCT190X5000
- PPN: SCH-PCSPCT190X5000
- UNSPSC: 39121032
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$921.69/ EA
Description
Designed for precision and reliability, the AccuSine+ auxiliary transformer from Schneider Electric serves as an essential component for measurement applications within electrical systems. With a rated operational voltage of 600 V AC and compatibility with a range of 50 to 400 Hz, this transformer effectively supports the AccuSine PCS+ active harmonic filter and the AccuSine PFV+ electronic VAR controller. Its robust construction includes a depth of 119.1 mm and a height of 124 mm, making it suitable for various mounting configurations. Weighing in at 1.8 kg, this transformer not only meets stringent safety certifications but also adheres to environmental regulations, ensuring responsible disposal in compliance with EU standards.
Specifications
Complementary Attributes
- UE Rated Operational Voltage
- 600 V AC 50...400 Hz
UIMP Rated Impulse Withstand Voltage10 kV (50 µs)
Important Information Attributes
- Continuous Thermal Current Rating Factor
- 1.33 30 °C, 1 55 °C
- Local Data Status
- Publishable
- Device Type
- Transformer - current transformer
- Traceability
- No
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant with Exemptions
- China ROHS In Scope
- Yes
- Without Single Use Plastic
- No
- Return Indicator
- N
- Current Transformer Ratio
- 5/5
- Package Weight Lbs
- 3.0 kg
- Product Or Component Type
- auxiliary transformer
- Returnability
- No
- Sustainable Packaging
- No
- Product Manager
- SREEMANT ROY
Range CompatibilityAccuSine AccuSine PCS+ active harmonic filter, AccuSine AccuSine PFV+ electronic VAR controller
Local Publishable Date2025-10-30
ServiceabilityNo
Scope PerimeterAt least in Europe
ROHS EUR StatusCompliant with Exemptions
ROHS EUR Full Compliance Status IdCOMPLIANT_WITH_EXEMPTIONS
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
WD Status5 - INITIALIZED WITH DataSCAN OK (Migration)
Electrical Connectionstuds2500 V
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
RangeAccuSine
Secondary Current5 A
Product Kit IdentifierN
Environment Attributes Main
- EU ROHS Directive
- Compliant By Exemption?, Compliant with Exemptions
- Take Back
- No
- China ROHS Regulation
- X
- Packaging Made With Recycled Cardboard
- No
ROHS Exemption InformationYes
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Packaging Without Single Use PlasticNo
General Attributes
- Product Or Component Type
- auxiliary transformer
Specifications
- Height
- 4.88 in
- Depth
- 0 in
Width4.5 in
