Killark DB-884 Junction Box 8 Inch x 8 Inch x 4 Inch, Copper-Free Aluminum, NEMA 3, 4, 4X
- MPN: DB-884
- UPC: 783936100098
- PPN: HBL-DB-884
CAD
$1913.02
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The DB series bolted enclosures are for use in locations with hazardous dust, are corrosive, wet, hose down, dirty, under both sever hot and cold ambient conditions. The DB series is UL / CSA certified Class II Groups EFG, Class III, Type 4 & 4X. The DBs are made of cast copper-free aluminum (less than 4/10 of 1%). Supplied standard with a mechanically fastened flat rubber cover gasket and separate cast mounting lugs. The boxes can be pre-drilled internally for factory or field installed mounting pans. Options include viewing windows, control operators, circuit breaker handles, NPT conduit openings.
Features
- Copper-free aluminum (less than 4/10 of 1%).
- Surface mounting type box with raised cover.
- Mounting lugs included as standard.
- Cover screws are stainless steel.
- Gaskets mechanically fastened to cover.
- All DB boxes cast with wall thicknesses suitable to drill and tap conduit openings.
- Conduit openings may be factory or field installed.
- Available blank or with factory modifications.
Documentation & Downloads
Specifications
General
- Color
- Gray
- Material
- Aluminum, Copper Free (less than 4/10 of 1%)
- Size
- 8" x 8" x 4"
- UPC
- 783936100098
Cover TypeBolted
SeriesDB
TypeJunction Box
Certifications and Compliance
- CSA File Number
- LR11716
- UL File Number
- E10514
Nema Rating3, 4, 4X
