Schneider Electric EMS58582 PowerLogic BAT24Ah 12V 24Ah 10 years life high rate industrial VRLA battery
Schneider Electric EMS58582 PowerLogic BAT24Ah 12V 24Ah 10 years life high rate industrial VRLA battery
- MPN: EMS58582
- PPN: SCH-EMS58582
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$345.65/ EA
Description
The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 125 mm in height, 175 mm in width and 166 mm in depth.
Features
- High-availability backup power supply
- 10 years lifespan
- VRLA battery
- 12V DC
Specifications
Important Information Attributes
- Local Data Status
- Publishable
- Device Type
- DC Systems - DC Power Systems
- Traceability
- Yes
- Average Life Duration
- 10 year(s)
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status Id
- CONTAINS_SVHC
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant
- China ROHS In Scope
- Yes
- Without Single Use Plastic
- Yes
- Return Indicator
- N
- Connector Type
- M5
- Energy Efficiency Optimized
- False
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Returnability
- No
- Sustainable Packaging
- No
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Stocking Flag
- Y
- Internal Resistance
- 20.47 mOhm IEC 60896-21
- Transfer Impedance
- 8.5 mOhm 1 kHz
Local Publishable Date2025-07-10
ServiceabilityYes
Field Service DivisionPSIBS
Legacy WEEE ScopeIn
Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
ROHS EUR StatusCompliant
ROHS EUR Full Compliance Status IdCOMPLIANT
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Dangerous Goods CodeBATTERIES WET NON SPILLABLE (ELECTRIC STORAGE or LEAD ACID)
Device Short NameBAT24AH
Package Weight Lbs9.785 kg
Range Of ProductPowerLogic T300
Short Circuit Current714 A IEC 60896-21
Tightening Torque2.5 N.m
Medium DescPowerLogic BAT24Ah 12V 24Ah 10 years life high rate industrial VRLA battery
Product Kit IdentifierN
Self Discharge Rate3 %, 1 month 20 °C
Global Commercial StatusCommercialised
Environment Attributes Main
- Take Back
- No, Nej
- EU ROHS Directive
- Compliant , Compliant
- ROHS Exemption Information
- Yes
- China ROHS Regulation
- X
- Mercury Free
- Yes
- Packaging Made With Recycled Cardboard
- No
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Ambient Air Temperature For Operation-15-50 °C charge, -15-50 °C charge, -20-60 °C discharge, -20-60 °C discharge, -15-50 °C charge, -15-50 °C charge, -20-60 °C discharge, -20-60 °C discharge
Product CompatibilityPS50, PS100, ITI3
Recycled Metal Content At Cr Level0 %
Toxic Heavy Metal FreeYes
Ambient Air Temperature For Storage-20-60 °C
Packaging Without Single Use PlasticYes
General Attributes
- Range Of Product
- PowerLogic T300
Output Attributes
- Output Voltage
- 12 V DC
Specifications
- Country of Origin
- United Kingdom, Sweden
Depth166 mm
Batteries & Runtime Attributes
- Removable Battery
- USER_REPLACEABLE, User replaceable
- Battery Type
- VRLA
Battery Life10 year(s) 20 °C Eurobat General Purpose
Battery Capacity25 Ah
