Schneider Electric EMS58583 PowerLogic T300 VRLA Battery 12V 38Ah 10 Years Life
- MPN: EMS58583
- PPN: SCH-EMS58583
CAD
$383.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 170 mm in height, 165 mm in width and 197 mm in depth.
Documentation & Downloads
Specifications
Key Specifications
| Battery Type | VRLA |
|---|---|
| Internal Resistance | 14.4 mOhm IEC 60896-21 |
| Transfer Impedance | 7.5 mOhm 1 kHz |
| Short-Circuit Current | 1005 A IEC 60896-21 |
| Output Voltage | 12 V DC |
|---|---|
| Range Of Product | PowerLogic T300 |
| Product Compatibility | PS50 || PS100 || ITI3 |
| Device Short Name | BAT38AH |
Complementary
| Connector Type | M5 |
|---|---|
| Height | 170 mm |
| Battery Life | 10 year(s) 20 °C EUROBAT |
| Width | 165 mm |
| Net Weight | 14.5 kg |
| Self-Discharge Rate | 3 %, 1 month 20 °C |
|---|---|
| Tightening Torque | 2.5 N.m |
| Battery Capacity | 40.6 Ah |
| Depth | 197 mm |
Offer Sustainability
| China Rohs Regulation | X |
|---|---|
| Rohs Exemption Information | Yes |
| Environmental Disclosure | ENVPEP120412EN |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Circularity Profile | ENVEOLI120408EN |
|---|---|
| Mercury Free | Yes |
| Sustainable Offer Status | Green Premium product |
| Eu Rohs Directive | Compliant |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
Environment
| Ambient Air Temperature For Storage | -20-60 °C |
|---|
| Ambient Air Temperature For Operation | -15-50 °C charge || -20-60 °C discharge |
|---|
