Bussmann ABC-30-R Fast-Acting Fuse 30A, 250 Vac, 125 Vdc, Ceramic, 0.25 Inch Diameter
- MPN: ABC-30-R
- UPC: 051712542487
- PPN: BUS-ABC-30-R
CAD
$1.97
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Fast-Acting Fuse 30A, 250 Vac, 125 Vdc, Ceramic, 0.25 Inch Diameter
Features
- Featuring a rugged ceramic body, this cartridge fuse is designed to withstand much higher internal pressures and temperatures than glass alternatives. This robust material ensures the fuse can contain heavy electrical arcs safely, eliminating the risk of the housing shattering during a catastrophic high-amperage short circuit.
- Engineered with a fast-acting speed profile, this fuse responds almost instantly to overcurrent anomalies, opening the circuit before damage can reach downstream electronic components. This rapid intervention is critical for safeguarding PLC power supplies, electronic instruments, and sensitive industrial control loops from permanent silicon breakdown.
- Boasting an interrupting rating of 200 Amps at 250V AC and up to 10,000 Amps at 125V AC, this small-dimension component is built to clear severe fault currents safely. This high clearing capacity prevents explosive arc-flash energy from damaging surrounding terminal blocks, wiring harnesses, or adjacent control panel components.
- Measuring exactly 1/4 inch by 1-1/4 inches (6.3mm x 32mm), this miniature fuse drops directly into industry-standard open-style clips, panel-mount blocks, and inline holders. This precise, universal mechanical footprint makes it a hassle-free, direct replacement for older glass AGC-style fuses when upgrading circuits to higher interrupting requirements.
Documentation & Downloads
Specifications
Additional
- Amperage
- 30A
- Interrupting Rating
- 200 AIC at 250 Vac, 1000 AIC at 125 Vac, 400 AIC at 125 Vdc, 1 kAIC at 75 Vdc
- Voltage Drop
- Typical: 0.09 V
- Resistance
- Typical DC cold: 0.002225 ohms
- Length
- 1.25 in
- Weight
- 0.008 lb
- Material
- Ceramic tube, nickel-plated brass endcaps
- Melting (L2T)
- Typical pre-arc: 1429
- UL Listed
- Guide JDYX & File E19180
Voltage Rating250 Vac, 125 Vdc, 32 Vac (self certified)
Response Time4 hr minimum at 100%, 60 min maximum at 135%, 120 s maximum at 200%
Fuse TypeFast-Acting
Diameter0.25 in
ConnectionFerrule end X ferrule end
Fuse IndicatorNon Indicating
TypeElectronic
CSA CertificationClass No: 1422-01 & 1422-30
