Bussmann FWH-15A14F High Speed Fuse 15A, 1000 Vac, 800 Vdc, 200 kAIC, Ferrule End X Ferrule End
- MPN: FWH-15A14F
- UPC: 051712370813
- PPN: BUS-FWH-15A14F
CAD
$41.87
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Fuse 15A, 1000 Vac, 800 Vdc, 200 kAIC, Ferrule End X Ferrule End
Specifications
Key Specifications
| Fuse Indicator | Non Indicating |
|---|---|
| Construction Size | 14 x 51 mm |
| Connection | Ferrule end X ferrule end |
| Amperage Rating | 15A |
| Utilization category | aR (accompanied semiconductor protection) |
| Type | High speed fuse |
| Breaking Capacity | 200 A |
| With Striker | No |
| Pre Arc (I2T) | 10 |
| Application | protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters |
| Voltage Type | AC/DC |
| Interrupt Rating | 200 kAIC Vac, 50 kAIC at 500 Vdc |
|---|---|
| Clearing (I2T) | Clearing at 500V: 40 |
| Release Characteristic | Other |
| Frequency Rating Maximum | 62 HZ |
| Watt Losses | 5.5W |
| Fuse Shape | cylindrical |
| Amperage Rating Numeric | 15 A |
| Frequency Rating Minimum | 45 HZ |
| Voltage Rating | 1000 Vac, 800 Vdc |
| Voltage Rating Numeric | 500 V |
| Packaging Type | Standard |
General
| UPC | 051712370813 |
|---|---|
| Product Length/Depth | 51 MM |
| Product Width | 14 MM |
| Warranty | Not Applicable |
| Certifications | CSA Certified |
| EAN | 5027590499552 |
|---|---|
| Product Height | 14 MM |
| Product Weight | 21.6 G |
| Compliances | CE Marked |
