Bussman

Bussman FWH-12A14F High Speed Fuse 12A 1000 Vac 800 Vdc Ferrule end x Ferrule end

High Speed Fuse 12A 1000 Vac 800 Vdc Ferrule end x Ferrule end
High Speed Fuse 12A 1000 Vac 800 Vdc Ferrule end x Ferrule end
  • MPN: FWH-12A14F
  • UPC: 051712795692
  • PPN: BUS-FWH-12A14F

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$37.85/ EA

Specifications

General

UPC
051712795692
Product Length/Depth
51 MM
Product Width
14 MM
Warranty
Not Applicable
Certifications
UL Recognized
EAN5027590499545
Product Height14 MM
Product Weight21.6 G
CompliancesCE Marked

Specifications

Fuse Indicator
Non Indicating
Construction Size
14 x 51 mm
Release Characteristic
Other
Frequency Rating Maximum
62 HZ
Type
High speed fuse
Breaking Capacity
200 A
With Striker
No
Voltage Rating
1000 Vac, 800 Vdc
Voltage Rating Numeric
500 V
Packaging Type
Standard
Interrupt Rating200 kAIC Vac, 50 kAIC at 500 Vdc
ConnectionFerrule end X ferrule end
Amperage Rating12A
Utilization categoryaR (accompanied semiconductor protection)
Fuse Shapecylindrical
Amperage Rating Numeric12 A
Frequency Rating Minimum45 HZ
Applicationprotection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Voltage TypeAC/DC
