Bussmann

Bussmann FWH-800A High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection

High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection
High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection
High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection
High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection
  • MPN: FWH-800A
  • UPC: 051712150248
  • PPN: BUS-FWH-800A

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$462.02/ EA

Description

High Speed Fuse 800A RMS, 8 Inch, 2.48 Inch Width, Blade Connection

Specifications

Specifications

Height
2.59 IN
Width
2.48 IN
Type
FWH, North American style
Voltage Rating
700 Vac (UL), 690 Vac (IEC), 500 Vdc (2-100A), 500 Vac
Interrupt Rating
200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
Mounting
Stud
Clearing (I2T)
Clearing at 500V: 409000
Pre Arc (I2T)
76200
Length8 IN
Weight1.96 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating800A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses129W
