Bussmann FWX-700A High Speed Fuse 700A RMS, 600V, 5.4 Inch Length, 2.2 Inch Height, Non Indicating
- MPN: FWX-700A
- UPC: 051712150750
- PPN: BUS-FWX-700A
CAD
$138.08
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
High Speed Fuse 700A RMS, 600V, 5.4 Inch Length, 2.2 Inch Height, Non Indicating
Documentation & Downloads
Specifications
Key Specifications
- Height
- 2.2 IN
- Width
- 2.1 IN
- Type
- FWX, North American style stud-mount
- Voltage Rating
- 600V
- Interrupt Rating
- 200 kAIC Vac, 50 kAIC at 250 Vdc
- Mounting
- Stud
- Clearing (I2T)
- Clearing at 250V: 190000
- Pre Arc (I2T)
- 48800
Length5.4 IN
Weight.8 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating700A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses72W
