Bussman

Bussman FWX-450A High Speed Fuse, 450A RMS, 600V, 1.63 Inch Height, 4.3 Inch Length

High Speed Fuse, 450A RMS, 600V, 1.63 Inch Height, 4.3 Inch Length
High Speed Fuse, 450A RMS, 600V, 1.63 Inch Height, 4.3 Inch Length
High Speed Fuse, 450A RMS, 600V, 1.63 Inch Height, 4.3 Inch Length
High Speed Fuse, 450A RMS, 600V, 1.63 Inch Height, 4.3 Inch Length
  • MPN: FWX-450A
  • UPC: 051712150729
  • PPN: BUS-FWX-450A

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$138.08/ EA

Specifications

Specifications

Height
1.63 IN
Width
1.62 IN
Type
FWX, North American style stud-mount
Voltage Rating
600V
Interrupt Rating
200 kAIC Vac, 50 kAIC at 250 Vdc
Mounting
Stud
Clearing (I2T)
Clearing at 250V: 101000
Pre Arc (I2T)
22100
Length4.3 IN
Weight.46 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating450A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses49W

Downloads
