Bussmann FWX-500A High-Speed Fuse 500A RMS 600V 1.63 Inch x 4.3 Inch
- MPN: FWX-500A
- UPC: 051712150736
- PPN: BUS-FWX-500A
CAD
$135.57
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
High-Speed Fuse 500A RMS 600V 1.63 Inch x 4.3 Inch
Documentation & Downloads
Specifications
Key Specifications
- Height
- 1.63 IN
- Width
- 1.62 IN
- Type
- FWX, North American style stud-mount
- Voltage Rating
- 600V
- Interrupt Rating
- 200 kAIC Vac, 50 kAIC at 250 Vdc
- Mounting
- Stud
- Clearing (I2T)
- Clearing at 250V: 128000
- Pre Arc (I2T)
- 28000
Length4.3 IN
Weight.46 LB
ApplicationDC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Amperage Rating500A RMS
ConnectionBlade end X blade end
Packaging TypeStandard
Fuse IndicatorNon Indicating
Watt Losses54W
