Bussmann 170M3022 High Speed Square Body Fuse 550A, 1250V, 200 kAIC, 45 MM Width, Class aR
- MPN: 170M3022
- UPC: 051712792745
- PPN: BUS-170M3022
CAD
$619.88
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Square Body Fuse 550A, 1250V, 200 kAIC, 45 MM Width, Class aR
Documentation & Downloads
Specifications
Key Specifications
| Height | 58 MM |
|---|---|
| Width | 45 MM |
| Type | Fuse |
| Voltage Rating | 1250V (IEC), 1300V (UL) |
| Amperage Rating | 550A |
| Interrupt Rating | 200 kAIC |
| Connection | Blade end X blade end |
| Mounting | DIN 43 620 |
| Clearing (I2T) | Clearing at 660V: 230000 |
| Fuse Shape | square body with centre-bolted tags (slotted) |
| Insulated Metal Gripping Lugs (IMGL) | No |
| Utilization category | aR (accompanied semiconductor protection) |
| Length | 104 MM |
|---|---|
| Weight | 366 G |
| Application | semiconductor protection |
| Voltage Rating Numeric | 690 V |
| Amperage Rating Numeric | 550 A |
| Class | Class aR |
| Construction Size | Other |
| Packaging Type | Standard |
| Clearing Loss | 75 |
| Fuse Indicator | Top fuse status indicator |
| Pre Arc (I2T) | Current pre-arc: 34000 |
| Voltage Type | AC |
