Bussmann 170M3986 High Speed Square Body Fuse 160A 1000V 150kAIC
- MPN: 170M3986
- UPC: 051712679022
- PPN: BUS-170M3986
CAD
$536.32
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Square Body Fuse 160A 1000V 150kAIC
Documentation & Downloads
Specifications
Key Specifications
- Height
- 61 MM
- Width
- 43 MM
- Type
- Fuse
- Voltage Rating
- 700V (UL), 690V (IEC)
- Amperage Rating
- 160A
- Interrupt Rating
- 150 kAIC
- Construction Size
- Other
- Packaging Type
- Standard
- Fuse Shape
- square body with centre-bolted tags (slotted)
- Insulated Metal Gripping Lugs (IMGL)
- No
- Utilization category
- aR (accompanied semiconductor protection)
- Watt Losses
- 45W
Length138 MM
Weight85 G
Applicationsemiconductor protection
Voltage Rating Numeric1000 V
Amperage Rating Numeric160 A
ClassClass aR
MountingDIN 43 620
Clearing (I2T)Clearing at 1000V: 17500
Fuse IndicatorTop fuse status indicator
Pre Arc (I2T)2850
Voltage TypeAC
